ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger

ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger

  • ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger
  • ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger
  • ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger
  • ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger
ASME SA182 F11 Cl.2 Front Channel For Heat Exchanger
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number: ASME SA 182 F11 CL.2
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10-90 Days
Payment Terms: L/C, T/T
Supply Ability: According To Client's Request
Contact Now
Detailed Product Description
Standard: ASME SA 182 Material: Stainless Steel
Material Grades: F11 CL.2 Type: Front Channel
Drawing: Customizable Size: Customizable
Highlight:

ASME SA182 Front Channel

,

Heat Exchanger Front Channel

,

ASME SA182 F11 Cl.2 Front Channel

ASME SA 182 F11 CL.2 FRONT CHANNEL





FRONT CHANNEL is a component used for connection in a heat exchanger.



We are manufacturer from China, we have 40 years experience ofr steel pipe / tube, fittings and flange, our products sell more than 85 countries up to now.



Advantage Products:Tube of Heat Exchanger / Boiler / Fin / U-bend, Equipment of Pressure Vessel / Heat Exchanger / Air cooler.

We provide support to many overseas end users, traders, stockists, and EPC companies.

If you need purchase, pls feel free to let me know. We will support you well.




ASME SA 182 F11 CL.2 refers to a specific grade of steel used in high temperature and high pressure applications, such as the construction of power plants, petrochemical plants, and other industrial environments. It is commonly used in flanges, forged fittings, valves, and other parts that require high strength and resistance to high temperatures and pressures.



CL.2 has higher mechanical properties compared to Grade 1. Known for its excellent creep rupture strength, it is often used in environments exposed to high temperatures for long periods of time.



Chemical Composition

Grade Symbol UNS Number Alloy Elements Composition %
F11 Class 2 K11572 1.25% chromium,
0.5% molybdenum
Carbon 0.10 - 0.20
Manganese 0.30 - 0.80
Phosphorus 0.040 max
Sulfur 0.040 max
Silicon 0.50 - 1.00
Chromium 1.00 - 1.50
Molybdenum 0.44 - 0.65





ASTM A182 F11 Class 2 Equivalent

Material Group Common Name Type UNS Forging Spec. Casting Spec. Equivalent DIN DIN W. No
ASTM A182 F11 Flange 1.1/4Cr-1/2Mo K11572 A182-F11 cl2 A217-WC6 13CRM044 1.7335 Up to 593ºC (1100ºF
