316L Hydraulic Stainless Steel Hose Fitting 90° Elbow

316L Hydraulic Stainless Steel Hose Fitting 90° Elbow

Material characteristics:

made of stainless steel, such as 304 or 316L stainless steel, with good corrosion resistance, high temperature resistance and high strength. It can adapt to the harsh working environment, resist the erosion of hydraulic oil and the influence of external environmental factors, and prolong the service life of the coupling core.

Structural design:

Usually 90 degree bending shape, can realise the connection of hydraulic hose in different directions, which is convenient for pipeline layout and system design. One end is connected with hydraulic hose (various models), the other end is connected with other hydraulic components or pipelines, and the connection parts are designed with corresponding interface forms, such as threads, ferrules, flanges, etc., to ensure the solidity and sealing of the connection.

Size specifications:

A wide range of size specifications are available to suit hydraulic hoses with different internal and external diameters and different working pressure requirements. Common sizes range from small diameters (e.g. 6mm, 8mm) to larger diameters (e.g. 25mm, 32mm, etc.). They can be customised according to the actual situation.

Sealing Principle:

Sealing is generally achieved through structures such as seals, gaskets or sealing cones. When the fitting core is assembled with hydraulic hoses and other connecting parts, these sealing elements will be squeezed or pressed to fill the gaps in the connecting parts and stop the hydraulic fluid leakage. For example, in some threaded joint cores, the seal is deformed by tightening the nut to achieve sealing; in ferrule joint cores, the ferrule shrinks radially under the action of the nut, hugging the tube and forming a seal with the tapered surface of the joint body.

Uses:
1.Hydraulic system connection: widely used in various hydraulic systems, such as construction machinery, mining machinery, agricultural machinery, ships, industrial equipment, etc., used to connect hydraulic hoses with hydraulic pumps, hydraulic cylinders, hydraulic motors, control valves and other hydraulic components, so that the hydraulic system forms a complete circuit to achieve the transmission and control of hydraulic energy.
2. Pipe steering: its 90-degree bend design can be used to change the direction of the hydraulic pipeline to adapt to different equipment layout and space requirements. In some complex hydraulic systems, it is necessary to reasonably arrange the pipelines through multiple 90-degree bend joint cores to avoid interference and collision between the pipelines, and at the same time to ensure the smooth flow of hydraulic oil.
3. Compensation for installation errors: In the installation process of the hydraulic system, due to deviations in the installation position of the equipment or the thermal expansion and contraction of the pipeline, etc., may lead to certain errors in the connection between the hydraulic hose and other components. Stainless steel 90 degree bend hydraulic hose fitting core has a certain degree of flexibility and adjustability, which can compensate for these installation errors to a certain extent, to ensure the reliability and sealing of the connection.

Service:

As a direct - factory, we cut out middlemen, offering you the lowest prices.  Our excellent service and customization options for various materials, specifications, and models are at your service.
