ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace

ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace

  • ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace
  • ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace
  • ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace
  • ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace
ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B366 UNS NO8810
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: According to Client Requirements/ Ply-wooden Case/ Iron Case/ Bundle with plastic Cap
Delivery Time: Depends on quantity
Payment Terms: T/T, L/C AT SIGHT
Supply Ability: According to Client Requirements
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Product Name: Nickel Alloy Steel Elbow Size: 1/8"NB TO 48"NB IN
Schedule: SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS Type: 180 DEG
Applications: Cellophane Manufacturing, Chlorination Systems, Pesticide Production, Incineration Scrubber Systems, Etc. Packaging: PLY-WOODEN CASE OR PALLET
Highlight:

180 Deg Elbow Buttweld Fitting

,

ASTM B366 stainless steel 180 elbow

,

UNS NO8810 stainless steel 180 elbow

ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace



ASTM B366 UNS N08810 elbow is an ideal choice for high temperature, corrosive media conveying systems, especially for extreme working conditions such as petrochemical cracking and nuclear power.



Its high nickel-chromium content and optimized carbon control design balance high temperature strength and corrosion resistance. For long-term high temperature applications (＞700°C), it is recommended to choose 800HT (UNS N08811) to optimize the lasting strength.





Equivalent Grades Of Incoloy 800H Pipe Fitting

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T



Chemical Composition Of Incoloy 800H Pipe Fitting

Grade C Mn Si S Cu Fe Ni Cr Al Ti
Incoloy 800H 0.05 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60



Mechanical Properties Of Incoloy 800H Pipe Fitting

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7.94 g/cm3 1350-1400 ℃ Psi - 75,000 , MPa -520 Psi - 30,000 , MPa - 205 30 - 35 %









Application scenarios





Petrochemical industry:

Ethylene cracking furnace outlet pipe elbow.

Catalytic reforming unit high temperature reactor connecting pipe.



Energy and nuclear power:

Nuclear reactor heat exchanger loop.

Gas turbine exhaust system.



Chemical equipment:

Ammonia synthesis unit high temperature gas pipeline.

Sulfuric acid regeneration system high temperature section.









ASTM B366 UNS NO8810 180 RETURN 180 Deg Elbow Buttweld Fitting For Ethylene Cracking Furnace 0
