ASME SA213 TP304L Stainless Steel Bright Annealed Seamless Tube For Heat Exchanger

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME SA213 TP304L

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	15-20days
Payment Terms:	L/C, T/T
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Standard:	ASME SA213	Material Grade:	TP304L, TP304, TP316, TP317, TP321, TP347
Application:	Heat Exchanger	Surface Condition:	Bright Annealed, Pickled
Type:	Seamless	Test:	Grain Size(ASTM E112), Flattening Test, Flaring Test, Hydrostatic Test, Nondestructive Electric Test
Highlight:	ASME SA213 Seamless Tube , Seamless Tube for Heat Exchanger , TP304L Stainless Steel Seamless Tube

ASME SA213 TP304L Stainless Steel Bright Annealed Seamless Tube for Heat Exchanger

Yuhong Group has specialized in supplying ASME SA213 TP304L stainless steel seamless tubes for heat exchangers for over 30 years. Our TP304L tubes, crafted from premium austenitic alloy with precise chemical composition, boast excellent corrosion resistance, high thermal durability, and robust mechanical strength.

ASME SA213 TP304L Steel Seamless Tube Chemical Composition

Grade	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Nickel
TP304L	0.035	2	0.045	0.03	1	18.0–20.0	8.0–12.0

ASME SA213 TP304L Equivalent specification

Region	Standard System	Specific Standard/Grade
China	GB	022Cr19Ni10 (00Cr19Ni10)
Japan	JIS	SUS 304L
South Korea	KS	STS 304L
USA	ASTM	304L
USA	UNS	S30403
European Standard (EN)	EN	X2CrNi 19 - 11, X2CrNi 18 - 9
European Standard (EN)	Numerical Designation	1.4306, 1.4307
Russia	GOST	03X18H10

Heat Treatment and Grain Size Requirements

Grade	Heat Treat Type	Austenitizing/Solutioning/Stabilizing Temperature(min or range)°F [°C]	Cooling Media
TP304L	solution treatment	1900 [1040]^F	water or other rapid cool

ASME SA213 TP304L Seamless Tube Mechanical Properties

Grade	UNS Designation	Tensile Strength, min, [MPa, ksi]	Yield Strength, min, [MPa, ksi]	Elongation in 2 in. or 50 mm, min, %B,C
TP304L	S30403	70 [485]	25 [170]	35

ASME SA213 TP304L Stainless Steel Seamless Tube Application in Heat Exchanger

ASME SA213 TP304L stainless steel seamless tubes are widely applied in heat exchangers. With excellent corrosion resistance from its chemical composition, good heat resistance, and high mechanical strength, they can withstand the harsh conditions of heat exchange processes. The seamless manufacturing ensures structural integrity, reducing leakage risks and enhancing thermal efficiency, making them a reliable choice for heat exchanger systems in industries like petrochemical.
