ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications

ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications

  • ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications
  • ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications
  • ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications
  • ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications
ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: API , ABS, DNV, GL , LR, NK.
Model Number: A182 F304
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80
Payment Terms: L/C, T/T
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Material: F304 Product Name: Stainless Steel Heat Flange
Pressure: 150lb,300lb,600lb,900lb,1500lb Standard: ANSI B16.5 ASME B16.47 SERIES A(MSS SP44)
Type: Threaded Flange,Slip On Flange,socket Weld Flange,weld Neck Flange,LAP Joint Flange Process: Forged,Drilling/Bending/Stamping,Casting,sand Casting&CNC Machining,Forging+machining+heating Treatment
Surface Treatment: Heat Treatment,Galvanized,Black Oxidation,customize,pickeling Inspection: Mechinical Property Inspection,Factory Or Third Party Assigned,100% Inspection
Highlight:

ASTM A182 F304 heat exchange flanges

,

high-temperature steel flanges with warranty

,

ASME SA-182 F304 high melting flanges

ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications





ASTM A182 / ASME SA-182 F304 flanges are forged flanges made of F304 grade stainless steel that conform to the ASTM A182 / ASME SA-182 standard. This material is commonly used for high-performance flanges in demanding applications.



ASTM A182 / ASME SA-182 covers forged or rolled alloy and stainless steel pipe flanges, forged fittings, and valves and components for high-temperature applications.



F304 offers excellent corrosion resistance in a wide range of atmospheric, chemical, and food/beverage environments.



Heater flanges are particularly common components in the following applications:



Fired heaters and boilers: Used to connect piping conveying hot fluids (oil, gas, steam, water) within or outside the heater structure.

Heat exchangers: Used to connect piping to the shell/tube side.

High-temperature process piping: Used in refineries, chemical/petrochemical plants, and power plants (fossil fuel and nuclear).









SS 304 Flanges Chemical Composition Standard

Grade C Mn Si P S Cr Mo Ni N
SS 304 0.08 max 2 max 0.75 max 0.045 max 0.030 max 18 – 20 - 8 – 11 -





Flange Mechanical Strength

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %













ASTM A182 F304 Flange Application







Key Applications:

Oil and gas refining (piping, heaters, reactors)

Chemical and petrochemical processing
Power generation (fossil fuel boilers, specialized steel grades for nuclear power)

Fired heaters and boilers
Heat exchangers

High-temperature steam systems
Food and beverage processing (hygienic applications typically use 304L)

Cryogenic systems (due to its good toughness at low temperatures)



ASTM A182 / ASME SA-182 F304 heat Exchange Flanges with High Melting Point for High-Temperature Applications 0
