ASME SA213 TP347H Seamless Tube Austenitic Stainless Steel Heat Exchanger & Boiler Tube

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A213 TP347, ASTM A213 TP347H

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	Depends on quantity
Payment Terms:	T/T,L/C
Supply Ability:	1000 Tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Highlight:

ASME SA213 TP347H seamless tube

austenitic stainless steel boiler tube

heat exchanger tube with warranty

ASME SA213 TP347H Seamless Tube Austenitic Stainless Steel Heat Exchanger & Boiler Tube

High-Temperature & Corrosion-Resistant Tubing for Critical Applications

ASTM A213 TP347H is a seamless, austenitic stainless steel tube specifically engineered for high-temperature service in demanding environments. Designated as a heat-resistant grade (indicated by the "H"), it delivers superior creep-rupture strength compared to its non-H counterparts, making it a reliable choice for pressure-bound applications.

This grade belongs to the niobium-stabilized Cr-Ni austenitic family. The addition of niobium (Nb) significantly enhances its resistance to intergranular corrosion, particularly in environments containing acids, alkalis, and salts. It offers better high-temperature strength and oxidation resistance than standard Type 316 stainless steel.

Primary Standards & Specifications

Governing Standard: ASTM A213/A213M - Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
Common Size Range: Outside diameter from 3.2 mm (1/8 in) to 127 mm (5 in) with minimum wall thickness ranging from 0.4 mm to 12.7 mm
Manufacturing Process: Seamless, available in hot-finished or cold-finished conditions

Material & Chemical Composition

TP347H is a high-carbon, niobium-stabilized austenitic stainless steel. The chemical composition ensures stability and strength under thermal stress.

Element	Composition Range (%)	Key Function
Carbon (C)	0.04 - 0.10	Enhances high-temperature strength
Manganese (Mn)	≤ 2.00	Improves hot ductility and strength
Silicon (Si)	≤ 1.00	Deoxidizer that improves oxidation resistance
Phosphorus (P)	≤ 0.045	Impurity element, controlled to low levels
Sulfur (S)	≤ 0.030	Impurity element, controlled to low levels
Chromium (Cr)	17.00 - 19.00	Provides fundamental corrosion and oxidation resistance
Nickel (Ni)	9.00 - 13.00	Stabilizes the austenitic structure and improves toughness
Niobium (Nb)	0.80 - 1.00 (or 8xC min)	Critical Element. Forms stable carbides to prevent chromium depletion at grain boundaries, granting exceptional resistance to intergranular corrosion

Mechanical & Physical Properties

TP347H offers a robust combination of strength, ductility, and stability for high-temperature operations.

Property	Standard Requirement
Tensile Strength	≥ 515 MPa (75 ksi)
Yield Strength (0.2% Offset)	≥ 205 MPa (30 ksi)
Elongation (A5)	≥ 35%
Hardness (Brinell)	≤ 192 HB

Main Application Scenarios

Thanks to its high-temperature strength, oxidation resistance, and corrosion stability, ASTM A213 TP347H tubes are the material of choice for critical components in several heavy industries:

Power Generation: Superheater and reheater tubes, main steam lines, and high-pressure boiler tubing in fossil fuel and thermal power plants
Petrochemical & Chemical Processing: Heat exchanger tubes, reactor internals, and piping systems that handle corrosive media at elevated temperatures
Oil & Gas Refining: Tubing for refinery heaters, heat recovery systems, and other high-temperature processing units
Other Industries: Also finds application in synthetic fiber, food, and paper industries where similar corrosion and temperature challenges exist
