ASTM A270 TP304 (UNS S30400）Bright Annealed Stainless Steel Tube For Industry Field

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	TUV, API, PED, ISO
Model Number:	ASTM A270 TP304

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Wooden Cases
Delivery Time:	Denpend on quantity
Payment Terms:	,T/T,L/C
Supply Ability:	30 Days

Contact Now

All Products

Stainless Steel Seamless Pipe (321)

Stainless Steel Seamless Tube (308)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (36)

Needle Tube (146)

Fin Tube (685)

Heat Exchanger (22)

Heat Exchanger Tube (452)

Heat Exchanger Tube Bundle (46)

Heat Exchanger Tubesheet (122)

Heat Exchanger Baffle (39)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (123)

Nickel Alloy Pipe (270)

Nickel Alloy Tube (93)

Copper Alloy Tube (245)

Alloy Steel Tube (206)

Titanium Tube (17)

Bright Annealed Tube (164)

Boiler Tube (151)

Steel Fitting (838)

Steel Flange (627)

Others (404)

Cladding Parts (8)

Detailed Product Description

Product:	ASTM A270 TP304 Bright Annealed Stainless Steel Tube	Material:	TP304 (UNS S30400)
OD (Outside Diameter):	6–152.4 Mm	WT (Wall Thickness):	1.2–3.05 Mm
Length:	Standard: 6 M (20 Ft); Custom: 3–12 M	Ends:	Plain Ends (PE), Deburred, Burr-Free; Optional: Beveled Ends (BE)
Highlight:	UNS S30400 Stainless Steel Tube , TP304 Bright Annealed Stainless Tube , ASTM A270 Stainless Steel Tube

ASTM A270 TP304 (UNS S30400)Bright Annealed Stainless Steel Tube For Industry Field

TP304 bright stainless steel tube is an austenitic product manufactured in strict accordance with ASTM A270 American Standard, designated as UNS S30400. As a bright-finish tubing, it is processed by precision drawing and polishing, with outstanding surface flatness and luster. This product is suitable for scenarios requiring high surface aesthetics and hygienic performance, and is widely used in global industrial and commercial fields.

Core Chemical Composition

Carbon (C)	Chromium (Cr)	Nickel (Ni)	Manganese (Mn)	Silicon (Si)	Phosphorus (P)	Sulfur (S)
≤0.08%	18.00%-20.00%	8.00%-10.50%	≤2.00%	≤1.00%	≤0.045%	≤0.030%

Core Supplementary Information

Product Advantages			Key Application Scenarios
ASTM A270 compliant, high-precision bright surface, excellent corrosion resistance, hygienic & easy to clean, stable mechanical properties.			Food & Pharmaceutical Industry, Medical Equipment, Electronic Industry, Sanitary Piping, Precision Instruments (require high surface quality and hygiene).

Dimensional & Bright Finish Specifications

Diameter (OD)	Wall Thickness (WT)	Standard Length	Surface Finish	OD Precision	WT Tolerance	Applicable Type	Cutting End Face
1/4 in (6.4mm) - 4 in (101.6mm) (Standard), Customizable up to 8 in (203.2mm)	0.020 in (0.51mm) - 0.4 in (10.16mm) (Standard), Customizable up to 0.6 in (15.24mm)	1m-12m (Custom Length on Demand)	Bright Annealed, Ra ≤ 0.8μm, Mirror-like Luster, No Scratches	±0.05mm	±0.05mm	Seamless Bright Tube	Smooth, Burr-Free, Precision

The TP304 bright stainless steel tube fully meets the strict requirements of ASTM A270 standard for surface finish, dimensional accuracy and performance. Its bright annealed surface forms an invisible protective film, which not only enhances corrosion resistance but also avoids dirt accumulation, ensuring long-term stable operation in hygienic and high-precision application scenarios. The product undergoes full-process quality control from raw material selection to finished product testing, with complete traceability of each batch, providing reliable material support for global customers.
