ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger

ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger

  • ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger
  • ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger
  • ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger
  • ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger
ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASME SA213 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 5-80 Days
Payment Terms: L/C, T/T, D/A
Supply Ability: 15000tons/month
Contact Now
All Products
Stainless Steel Seamless Pipe (336)
Stainless Steel Seamless Tube (326)
Duplex Stainless Steel Pipe (134)
Duplex Stainless Steel Tube (38)
Needle Tube (163)
Fin Tube (710)
Heat Exchanger (31)
Heat Exchanger Tube (468)
Heat Exchanger Tube Bundle (50)
Heat Exchanger Tubesheet (125)
Heat Exchanger Baffle (39)
Air Cooler (13)
Pressure Vessel (4)
Stainless Steel Welded Pipe (61)
Stainless Steel Welded Tube (132)
Nickel Alloy Pipe (276)
Nickel Alloy Tube (104)
Copper Alloy Tube (251)
Alloy Steel Tube (212)
Titanium Tube (21)
Bright Annealed Tube (173)
Boiler Tube (153)
Steel Fitting (864)
Steel Flange (663)
Others (407)
Cladding Parts (9)
Detailed Product Description
Products: ASME SA213 TP316L Tube Steel Grade: TP316L
Type: Seamless U Bend Tube Certification: ISO,SGS,BV,ISO & SGS,ISO/CE/SGS
Length: 3000mm~6000mm,6 Meters Or Customized,18000max.,11.8m Or As Required.,8m Thickness: 0.4-30mm,1.0mm,0.6mm~2500mm,1mm-60mm,0.6 To 25 Mm
Packing: Wooden Box Packaging
Highlight:

ASME SA213 TP316L seamless tube

,

heat exchanger corrosion resistant tube

,

stainless steel seamless tube no PWHT

ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger

The core technological advantage of ASME SA213 TP316L seamless steel pipe lies in its ultra-low carbon content. During welding, the heat-affected zone inevitably experiences a sensitization temperature range of 450℃ to 850℃.

TP316L stainless steel, by reducing the carbon content to below 0.035%, results in extremely low free carbon content at the grain boundaries for Cr₂₃C₆ formation—even across the sensitization temperature range, grain boundary carbides cannot form a continuous network, thus preventing chromium-depleted zones. Therefore, TP316L stainless steel pipe requires no post-weld heat treatment and can be used directly after welding.





Supporting Standard System
Standard Product Form Application
ASME SA213 / A213 Seamless Tube Boiler, Superheater, Heat Exchanger
ASME SA249 / A249 Welded Tube Boiler, Superheater, Heat Exchanger, Condenser
ASTM A312 Seamless / Welded Pipe Process Piping, Fluid Transportation
ASME SA269 / A269 Seamless / Welded Tube General Service
ASME SA688 / A688 Welded Tube Feedwater Heater



ASME SA213 TP316L Chemical Composition Requirements
Element Content Range (%) Function Description
C (Carbon) ≤ 0.035 Low carbon design – prevents intergranular corrosion
Mn (Manganese) ≤ 2.00 Deoxidation, improves hardenability
P (Phosphorus) ≤ 0.045 Cold brittleness control
S (Sulfur) ≤ 0.030 Hot brittleness control
Si (Silicon) ≤ 1.00 Oxidation resistance improvement
Cr (Chromium) 16.0 – 18.0 Oxidation resistance & high-temperature strength
Ni (Nickel) 10.0 – 14.0 Austenite structure stabilization
Mo (Molybdenum) 2.0 – 3.0 Pitting resistance & creep strength improvement
N (Nitrogen) ≤ 0.10 Solid solution strengthening (reference)





TP316L vs TP316 Chemical Composition Comparison
Element TP316L TP316 Difference
C ≤0.035% ≤0.08% TP316L carbon content reduced by >56%
Cr 16.0-18.0% 16.0-18.0% Same
Ni 10.0-14.0% 10.0-14.0% Same
Mo 2.0-3.0% 2.0-3.0% Same



TP316 is suitable for machined parts that do not require welding, or for applications where post-weld solution heat treatment is possible. It is particularly advantageous for applications requiring high strength.

TP316L is suitable for scenarios requiring extensive welding, such as tube-to-tube sheet welding of heat exchanger tube bundles, on-site process piping, and large structural components where post-weld heat treatment is not feasible. TP316L eliminates the need for post-weld heat treatment, significantly simplifying the manufacturing process, reducing energy consumption, and avoiding the risk of deformation during heat treatment.

If welding is required, choose TP316L; if welding is not required or post-weld solution treatment is possible, choose TP316. There is no absolute superiority of one over the other; the difference lies in the suitability of the application scenario.




ASME SA213 TP316L Minimum Mechanical Properties
Parameter Value Standard Reference
Tensile Strength (Rm) ≥ 485 MPa ASME SA213
Yield Strength (Rp0.2) ≥ 170 MPa ASME SA213
Elongation (50mm gage length) ≥ 35% ASME SA213
Hardness (HRB) ≤ 90 ASME SA213
Hardness (HBW) ≤ 192 ASME SA213
Hardness (HV) ≤ 200 ASME SA213



Mechanical Properties (Typical Annealed Values)
Parameter Typical Value
Yield Strength ≥ 205 MPa
Tensile Strength ≥ 515 MPa
Elongation ≥ 35%
Hardness ≤ 90 HRB





Typical applications of TP316L

  • Heat exchanger tube bundles (tube-to-tube sheet welding) – extensive welding and difficult to perform integral PWHT

  • Boilers and superheater tubes (ASME SA213 coverage)

  • Petrochemical process pipelines (field welding, in-furnace solution treatment not possible)Marine engineering and ship piping

  • Nuclear power auxiliary systems;

  • Pharmaceutical and food processing equipment (high purity requirements)



ASME SA213 TP316L Seamless Tube C≤0.035% No PWHT After Welding Intergranular Corrosion Resistant For Heat Exchanger 0
