Super Duplex 2507 Flange ASTM A182 UNS S32750 / F53 Super Duplex Weld Neck Flange

ASTM A182 F53 / UNS 32750 / Super Duplex 2507 Weld Neck Flange WNRF Flange

A Super Duplex 2507 Weld Neck Flange is a high-strength, corrosion-resistant pipe connecting component manufactured from forged super duplex stainless steel grade UNS S32750 (ASTM A182 Grade F53). "Weld Neck" is a long, tapered hub that transitions smoothly into the pipe wall via a single butt-weld joint. This flange is defined by its balanced dual-phase microstructure (approximately 50% austenite / 50% ferrite), which provides exceptional mechanical strength and outstanding resistance to localized corrosion in highly aggressive environments. It is fully compliant with the ASTM A182 standard for forged components used in high-temperature and high-pressure services.

Chemical Composition of ASTM A182 F53 Super Duplex Steel Flange Duplex 2507 Weld Neck Flange

Mechanical properties of ASTM A182 F53 Super Duplex Steel Flange Duplex 2507 Weld Neck Flange

Application

You will find this specific flange in environments where both mechanical strength and corrosion resistance are paramount:

• Oil & Gas: Subsea manifolds, offshore platform risers, and high-pressure wellhead equipment (handling sour gas/CO₂/H₂S).

• Chemical Processing: Heat exchangers and piping carrying chlorides, acetic acid, or sulfuric acid.

• Marine/Desalination: Seawater cooling systems and reverse osmosis high-pressure piping.

• Pulp & Paper: Bleaching plants (handling chlorine dioxide).

NO CRACK (PT TEST)
