Stainless Steel Heat Exchanger Tube Stainless steel welded tube ASTM A249 TP304 TP304L With High Performance,Pickled Annealed
YUHONG GROUP deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 25 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.
Heat Exchanger Tube Specification:
ASTM A249 / A249M:Standard Specification for Welded Austenitic Steel Boiler, Superheater
Heat-Exchanger, and Condenser Tubes.
Other Standard:DIN 17456 , DIN 17458, EN10216-5, JIS-G3463,...
| Grade |
Material
number |
C |
Si |
Mn |
P |
S |
N |
Cr |
Mo |
Ni |
Ti |
others |
| Ferritic or martensitic steels |
| X2CrTi12 |
1.4512 |
 0.030 |
1.00 |
1.00 |
0.040 |
0.015 |
|
10.50to12.50 |
|
|
6×(C+N)to0.65 |
|
| X6CrAl13 |
1.4002 |
0.08 |
1.00 |
1.00 |
0.040 |
0.015 |
|
12.00to14.00 |
|
|
|
0.10to0.30Al |
| X6Cr17 |
1.4016 |
0.08 |
1.00 |
1.00 |
0.040 |
0.015 |
|
16.00to18.00 |
|
|
|
|
| X3CrTi17 |
1.4510 |
0.05 |
1.00 |
1.00 |
0.040 |
0.015 |
|
16.00to18.00 |
|
|
4×(C+N)+0.15 to 0.80 |
|
| X12Cr13 |
1.4006 |
0.08 to 0.15 |
1.00 |
1.50 |
0.040 |
0.015 |
|
11.50to13.50 |
|
0.75 |
|
|
| Austenitic steels |
| X5CrNi18-10 |
1.4301 |
0.07 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
17.00to19.50 |
|
8.00to10.50 |
|
|
| X2CrNi19-11 |
1.4306 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
18.00to20.00 |
|
10.00to12.00 |
|
|
| X2CrNiN18-10 |
1.4311 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.12to0.22 |
17.00to19.50 |
|
8.50to11.50 |
|
|
| X6CrNiTi18-10 |
1.4541 |
0.08 |
1.00 |
2.00 |
0.045 |
0.015 |
|
17.00to19.00 |
|
9.00to12.00 |
5×C to 0.70 |
|
| X6CrNiNb18-10 |
1.4550 |
0.08 |
1.00 |
2.00 |
0.045 |
0.015 |
|
17.00to19.00 |
|
9.00to12.00 |
|
10×Cto1.00Nb |
| X5CrNiMo17-12-2 |
1.4401 |
0.07 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
16.50to18.50 |
2.00to2.50 |
10.00to13.00 |
|
|
| X2CrNiMo17-12-2 |
1.4404 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
16.50to18.50 |
2.00to2.50 |
10.00to13.00 |
|
|
| X6CrNiMoTi17-12-2 |
1.4571 |
0.08 |
1.00 |
2.00 |
0.045 |
0.015 |
|
16.50to18.50 |
2.00to2.50 |
10.50to13.50 |
5×C to 0.70 |
|
| X2CrNiMoN17-13-3 |
1.4429 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.12to0.22 |
16.50to18.50 |
2.50to3.00 |
11.00to14.00 |
|
|
| X2CrNiMo18-14-3 |
1.4435 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
17.00to19.00 |
2.50to3.00 |
12.50to15.00 |
|
|
| X3CrNiMo17-13-3 |
1.4436 |
0.05 |
1.00 |
2.00 |
0.045 |
0.015 |
0.11 |
16.50to18.50 |
2.50to3.00 |
10.50to13.00 |
|
|
| X2CrNiMoN17-13-5 |
1.4439 |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
0.12to0.22 |
16.50to18.50 |
4.00to5.00 |
12.50to14.50 |
|
|
| Tube Sizes for Heat Exchangers & Condensers & Boiler |
| |
|
|
|
|
|
|
|
|
|
| Outside Diameter |
|
BWG |
| 25 |
22 |
20 |
18 |
16 |
14 |
12 |
10 |
| |
Wall Thickness mm |
| 0.508 |
0.71 |
0.89 |
1.24 |
1.65 |
2.11 |
2.77 |
3.40 |
| mm |
inch |
|
Weight kg/m |
| 6.35 |
1/4 |
0.081 |
0.109 |
0.133 |
0.174 |
0.212 |
|
|
|
| 9.53 |
3/8 |
0.126 |
0.157 |
0.193 |
0.257 |
0.356 |
0.429 |
|
|
| 12.7 |
1/2 |
|
0.214 |
0.263 |
0.356 |
0.457 |
0.612 |
0.754 |
|
| 15.88 |
5/8 |
|
0.271 |
0.334 |
0.455 |
0.588 |
0.796 |
0.995 |
|
| 19.05 |
3/4 |
|
0.327 |
0.405 |
0.553 |
0.729 |
0.895 |
1.236 |
|
| 25.4 |
1 |
|
0.44 |
0.546 |
0.75 |
0.981 |
1.234 |
1.574 |
2.05 |
| 31.75 |
1 1/4 |
|
0.554 |
0.688 |
0.947 |
1.244 |
1.574 |
2.014 |
2.641 |
| 38.1 |
1 1/2 |
|
0.667 |
0.832 |
1.144 |
1.514 |
1.904 |
2.454 |
3.233 |
| 44.5 |
1 3/4 |
|
|
|
1.342 |
1.774 |
2.244 |
2.894 |
3.5 |
| 50.8 |
2 |
|
|
|
1.549 |
2.034 |
2.574 |
3.334 |
4.03 |
| 63.5 |
2 1/2 |
|
|
|
1.949 |
2.554 |
3.244 |
4.214 |
5.13 |
| 76.2 |
3 |
|
|
|
2.345 |
3.084 |
3.914 |
5.094 |
6.19 |
| 88.9 |
3 1/2 |
|
|
|
2.729 |
3.609 |
4.584 |
5.974 |
7.27 |
| 101.6 |
4 |
|
|
|
|
4.134 |
5.254 |
6.854 |
8.35 |
| 114.3 |
4 1/2 |
|
|
|
|
4.654 |
5.924 |
7.734 |
9.43 |
| Form of Tube: Straight & U-bend & Finned & Coiled |
|
|
|
|
|
|
|
|
|
| Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81. |
|
|
|
|
|
|
|
|
|
| Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213 |
|
|
|
|
|
|
|
|
|
Material Grade:
Size Range:
| Production |
Outside Diameter |
Wall Thickness |
| Heat Exchanger Tube |
6.00mm to 101.6mm |
0.5mm to 8mm |
Final Finishing
Solution Annealed & Pickled/Bright Annealed.
Type of Tubes:
U-bend & Straight.
Some of the quality tests carried out by us includes:
| Corrosion Test |
Conducted only when specially requested by the client |
| Chemical Analysis |
Test done as per required quality standards |
| Destructive / Mechanical Testing |
Tensile | Hardness | Flattening | Flare | Flange |
| Reverse-bend and Re. flat tests |
Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end |
| Eddy Current Testing |
Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System |
| Hydrostatic Testing |
100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s . |
| Air Under Pressure Test |
To check any evidence of air leakage |
| Visual Inspection |
After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections |
Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:
- Eddy Current Testing
- O.P Testing
- Radiography Testing
|
- Corrosion Testing
- Micro Testing
- Macro Testing
|
- IGC Testing
- Ultrasonic testing
- Liquid Penetrate testing
|
