ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube A178 GR.A GR.C , A179 , A192, A209, A210, A213

ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube A178 GR.A GR.C , A179 , A192, A209, A210, A213

ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube A178 GR.A GR.C , A179 , A192, A209, A210, A213
video
ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube A178 GR.A GR.C , A179 , A192, A209, A210, A213
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ISO9001-2008, API 5L, API 5CT
Model Number: ASTM A214 ASME SA214 ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube, A178 , GR.A , GR.C , A179 , A192, A209, A210, A213
Payment & Shipping Terms:
Minimum Order Quantity: 5 tons
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 7 DAYS
Payment Terms: L/C AT SIGHT, T/T
Supply Ability: 1000 TONS PER MONTH
Contact Now
Detailed Product Description
Standard: ASTM A214 , ASME SA214 ,BS3059, ASME SA178 ,DIN17175 Grade: Grade A, C, D, 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2, ST35.8, ST45.8
Type Of Tube:: Staight ,Tube, U Bend Tube Application:: For High, Middle, Low Pressure Boiler And Pressure Purpose
High Light:

boiler pipe

,

boiler condensate pipe



ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube A178 GR.A GR.C , A179 , A192, A209, A210, A213





Application: For high, middle, low pressure boiler and pressure purpose





Production Standard, Grade, Steel No:

ASTM A178 Grade A, C, D

ASTM A179 Grade A, C, D

ASTM A192

ASTM A210 GradeA-1, C

BS3059-Ⅰ 320 CFS

BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2

EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2

EN10216-2 P195GH, P235GH, P265GH, TC1, TC2

DIN17175 ST35.8, ST45.8

DIN1629 ST37.0, ST44.0, ST50.0

JIS G3454 STPG370, STPG410

JIS G3461 STB340, STB410, STB440

GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB

GB9948 10, 20, 12CrMo, 15CMo

GB3087 10, 20

Delivery Condition:Annealed, Normalized, Normalized and Tempered



Inspection and Test:

Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength,Yield Strength,

Elongation, Flaring, Flattening, Bending, Hardness, Impact Test), Surface and Dimension Test,No-destructive Test, Hydrostatic Test.



Surface treatment:

Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting



Tube Sizes for Heat Exchangers & Condensers & Boiler
Outside Diameter   BWG
25 22 20 18 16 14 12 10
  Wall Thickness mm
0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40
mm inch   Weight kg/m
6.35 1/4 0.081 0.109 0.133 0.174 0.212
9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429
12.7 1/2   0.214 0.263 0.356 0.457 0.612 0.754
15.88 5/8   0.271 0.334 0.455 0.588 0.796 0.995
19.05 3/4   0.327 0.405 0.553 0.729 0.895 1.236
25.4 1   0.44 0.546 0.75 0.981 1.234 1.574 2.05
31.75 1 1/4   0.554 0.688 0.947 1.244 1.574 2.014 2.641
38.1 1 1/2   0.667 0.832 1.144 1.514 1.904 2.454 3.233
44.5 1 3/4       1.342 1.774 2.244 2.894 3.5
50.8 2       1.549 2.034 2.574 3.334 4.03
63.5 2 1/2       1.949 2.554 3.244 4.214 5.13
76.2 3       2.345 3.084 3.914 5.094 6.19
88.9 3 1/2       2.729 3.609 4.584 5.974 7.27
101.6 4         4.134 5.254 6.854 8.35
114.3 4 1/2         4.654 5.924 7.734 9.43
Form of Tube: Straight & U-bend & Finned & Coiled
Stainless Steel Tube: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81.
Carbon &Alloy Steel Tube: A/SA178, A/SA179, A/SA192,A/SA209, A/SA210, A/SA213, A.SA214



ASTM A214 ASME SA214 welded Carbon Steel Boiler Tube,  A178 , GR.A , GR.C  , A179 , A192, A209, A210, A213
