ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger

ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger

  • ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger
  • ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger
  • ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger
  • ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger
ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A213 / ASME SA213 T11, T22, T1, T23, T5, T9.T91 , T92
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: USD
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 15 DAYS
Supply Ability: 1500 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (224)
Stainless Steel Seamless Tube (178)
Stainless Steel Welded Pipes (41)
Stainless Steel Welded Tube (77)
Finned Tube (204)
Heat Exchanger Tube (131)
Duplex Stainless Steel Pipes (111)
Alloy Steel Seamless Tubes (62)
Bright Annealed Tube (146)
Copper Alloy Tube (131)
Nickel Alloy Pipe (264)
Carbon Steel Pipe (50)
U Bend Tube (140)
Boiler Tube (72)
Steel Pipe Fittings (530)
Steel Flanges (374)
Steel Valves (12)
Precision Steel Strip (23)
Alloy Wires (271)
Heat Exchanger Parts (44)
Detailed Product Description
GRADE: T1,T11, T12, T2, T22, T23, T5, T9, T91, T92 STANDARD: ASTM A213 / SMES SA213
OD: 1/4'' TO 5'' NDT: ET/UT/HT
High Light:

alloy steel tube

,

stainless steel round tube



ASTM A213 / ASME SA213 T9 T91 T92 Alloy Steel Seamless tube for Boiler , Superheater , Heat exchanger application



Yuhong Group supply huge qty of Cr-Mo Alloy seamless pipe and tube , and export more than 40 countries . Our alloy seamless tube be width used in boiler and heating.



YUHONG controls the entire manufacturing process from raw material to finished products, Inspection points are localed in the manufacturing process to ensure all products meet all requirements. In such quality control system, faults are detected at the earliest possible stage of the production process in order to eliminate the risk of rejection at final inspection. We have made continuous efforts to reduce the problem throughout total quality assurance system including traceability control, YUHONG not only inspect by ourself , also through TPI like BV, SGS, DNV, ABS, MOODY, IBR, so that today the quality of our productsis clearly recognized by our client.




Carbon Chromiun Low Temperature Stainless Steel Duplex Copper& Bronze Titanium Ni-Alloy
SA178-A SA213-T1 SA333-Gr.1 SA213 TP316L A789-S31803 SB111-C70600 SB338-GR.1 SB163 NO2200
SA178-C SA213-T11 SA333-Gr.3 SA249 TP316H A789-S32205 SB111-C71500 SB338-GR.2 SB167 NO2201
SA179 SA213-T12 SA333-Gr.6 SA268 TP316Ti A789-S32750 SB111-C71640 SB338-GR.5 SB444 NO8020
SA192 SA213-T22 SA333-Gr.7 SA269 TP316LN A789-S32760 SB111-C68700 SB338-GR.7 SB514 NO6022
SA209-T1 SA213-T5 SA333-Gr.8 SA376 TP321 A789-S32707 SB111-C44300 SB338-GR.9 SB619 N10276
SA209-T1a SA213-T9 SA334-Gr.1 TP304 TP321H A789-S32304 　 SB338-GR.12 SB622 NO4400
SA209-T1b SA213-T91 SA334-Gr.3 TP304L TP347 A789-S31500 　 　 SB626 NO6600
SA210-A1 　 SA334-Gr.6 TP304H TP347H S31254 　 　 SB674 NO6601
SA210-C 　 SA334-Gr.7 TP304N TP405 254MA 　 　 SB677 NO6625
SA214 　 SA334-Gr.8 TP310H TP409 17-4PH 　 　 SB704 NO690
SA513 MT 1010 　 　 TP310S TP410 17-7PH 　 　 SB705 NO8800
SA513 MT 1015 　 　 TP309S TP430 15-7PH 　 　 N1001 NO8810
SA513 MT 1020 　 　 TP317 TP439 　 　 　 N10665 NO8811
　 　 　 TP317L TP444 　 　 　 N10675 NO8825
　 　 　 TP348 TP446 　 　 　 TP904L 　
　 　 　 TP347HFG 　 　 　 　 　 　





Tube Sizes for Heat Exchangers & Condensers & Boiler

Outside Diameter 　 BWG
25 22 20 18 16 14 12 10
　 Wall Thickness mm
0.508 0.71 0.89 1.24 1.65 2.11 2.77 3.40
mm inch 　 Weight kg/m
6.35 1/4 0.081 0.109 0.133 0.174 0.212 　 　 　
9.53 3/8 0.126 0.157 0.193 0.257 0.356 0.429 　 　
12.7 1/2 　 0.214 0.263 0.356 0.457 0.612 0.754 　
15.88 5/8 　 0.271 0.334 0.455 0.588 0.796 0.995 　
19.05 3/4 　 0.327 0.405 0.553 0.729 0.895 1.236 　
25.4 1 　 0.44 0.546 0.75 0.981 1.234 1.574 2.05
31.75 1 1/4 　 0.554 0.688 0.947 1.244 1.574 2.014 2.641
38.1 1 1/2 　 0.667 0.832 1.144 1.514 1.904 2.454 3.233
44.5 1 3/4 　 　 　 1.342 1.774 2.244 2.894 3.5
50.8 2 　 　 　 1.549 2.034 2.574 3.334 4.03
63.5 2 1/2 　 　 　 1.949 2.554 3.244 4.214 5.13
76.2 3 　 　 　 2.345 3.084 3.914 5.094 6.19
88.9 3 1/2 　 　 　 2.729 3.609 4.584 5.974 7.27
101.6 4 　 　 　 　 4.134 5.254 6.854 8.35
114.3 4 1/2 　 　 　 　 4.654 5.924 7.734 9.43





ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Chemical Composition and Mechanical Properties

Grade Chemical Composition%
C Si Mn P, S Max Cr Mo Ni Max V Al Max
T2 0.10~0.20 0.10~0.30 0.30~0.61 0.025 0.50~0.81 0.44~0.65 – – –
T11 0.05~0.15 0.50~1.00 0.30~0.60 0.025 1.00~1.50 0.44~0.65 – – –
T12 0.05~0.15 Max 0.5 0.30~0.61 0.025 0.80~1.25 0.44~0.65 – – –
T22 0.05~0.15 Max 0.5 0.30~0.60 0.025 1.90~2.60 0.87~1.13 – – –
T91 0.07~0.14 0.20~0.50 0.30~0.60 0.02 8.0~9.5 0.85~1.05 0.4 0.18~0.25 0.015
T92 0.07~0.13 Max 0.5 0.30~0.60 0.02 8.5~9.5 0.30~0.60 0.4 0.15~0.25 0.015
Grade Chemical Composition% Mechanical Properties
W B Nb N T. S Y. P Elongation Hardness
T2 – – – – ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T11 – – – – ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T12 – – – – ≥ 415MPa ≥ 220MPa ≥ 30% 163HBW(85HRB)
T22 – – – – ≥ 415MPa ≥ 205MPa ≥ 30% 163HBW(85HRB)
T91 – – 0.06~0.10 0.03~0.07 ≥ 585MPa ≥ 415MPa ≥ 20% 250HBW(25HRB)
T92 1.50~2.00 0.001~0.006 0.04~0.09 0.03~0.07 ≥ 620MPa ≥ 440MPa ≥ 20% 250HBW(25HRB)

ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Tolerance

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % – + 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, – 0 mm
  • T11 Alloy Steel Tube for power generation, petroleum, and other high temperature services
  • T22 Alloy Steel Tube for power generation, petroleum, and other high temperature services
  • T5 Alloy Steel Tube for petroleum
  • T9 Alloy Steel Tube for petroleum
  • T91 Alloy Steel Tube for power generation
  • T92 Alloy Steel Tube for power generation
  • T1 Alloy Steel Tube for boiler replacement and repair
  • SA209 T1 tube for Manufacturing Boilers
  • ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Superheaters
  • ASTM A213/ ASME SA213 T5 Alloy Steel Tube for Heat Exchangers

ASTM A213 / SMES SA213 Alloy Steel Seamless Tubes For Boiler / Heat Exchanger 0
