Seamless Carbon Steel Boiler Tubing / tube / tubes,DIN2391 ST37.4 NBK

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ISO9001-2008, API 5L, API 5CT
Model Number:	ST37.4, ST52.4

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Packaging Details:	PLYWOOD CASE,BUNDLE,PALLET
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

OD:	3/4" (19.05), 1"(25.4) , 1-1/4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2)	LENGTH:	6000MM,6096MM,SRL,DRL
MATERIAL:	ST37.4, ST52.4	USAGE:	Heat Exchanger Tube, Boiler Tube
STANDARD:	DIN 2391C NBK
Highlight:	carbon steel seamless tube , boiler condensate pipe

Seamless Carbon Steel Boiler Tubing / tube / tubes,DIN2391 ST37.4 NBK

DIN2391 Precision Cold Drawn Seamless Pipes and Tubes, Gr St35 St45 St52 St37.4, Cold Finished Seamless Pipe use for Hydraulic and Pneumatic.

Delivery Status: NBK (+N) BKW (+LC) GBK (+A) BKS (+SR) BK (+C) OD x WT = 4~120 x 0.5~15mm

DIN2391 St52.4+N Phosphated Hydraulic Tube

Normalized NBK

The last cold forming process is followed by annealing above the upper transformation point in a controlled

atmosphere.

Chemical Composition:

Steel grade		Chemical composition, as a percentage by mass
Symbol	Material number	C max.	Si max.	Mn	P max.	S max.
St 30 Si	1.0211	0.10	0.30	<=0.55	0.025	0.025
St 30 Al	1.0212	0.10	0.05	<=0.55	0.025	0.025
St 35	1.0308	0.17	0.35	<=0.40	0.025	0.025
St 45	1.0408	0.21	0.35	<=0.40	0.025	0.025
St 52	1.0580	0.22	0.55	<=1.60	0.025	0.025
The following alloying elements may be added: Nb: <=0,03%; Ti: <=0,03%; V: <=0,05%; Nb + Ti + V: <=0,05%.

Steel grade		Chemical Composition(%):
Steel name	Steel number	C max	Si max	Mn	P max	S max	Al min
E215	1.0212	0.10	0.05	0.70	0.025	0.025	0.025
E235	1.0308	0.17	0.35	1.20	0.025	0.025	-
E355	1.0580	0.22	0.55	1.60	0.025	0.025	-
