| Model Number: | ASTM A815 Duplex 2205 WPS32205-S 180 Degree U Bend Pipe Fitting |
| Minimum Order Quantity: | 100KGS |
|---|---|
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 7 DAYS |
| Payment Terms: | L/C,T/T |
| Product Name: | Elbow 180 Degree U-bend Fitting | Standard: | ASTM A815 |
|---|---|---|---|
| Material: | Duplex 2205, (S31803/S32205) | O.D.: | 1/8'' TO 100'' |
| W.T.: | SCH10/STD/40/XS/80/160/XXS | Type: | SEAMLESS,WELDED |
| Inspection: | RT, UT, PT | Connection: | Butt Weld |
| Shape: | 180 Degree U Bend | Applications: | Petrochemical, Natural Gas, Nuclear Power, Space And Aviation, Environmental Protection, Etc. |
| High Light: | UNS S32205 180 Degree Elbow,180 Degree U Bend Pipe Fittings,ASTM A815 180 Degree Elbow |
||
ASTM A815 Duplex 2205 WPS32205-S 180 Degree U Bend Butt Weld Pipe Fittings
We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.
ASTM A815 specification covers two general classes, WP and CR, of wrought ferritic, ferritic/austenitic, and martensitic stainless steel fittings of seamless and welded construction. Class WP fittings are subdivided into four subclasses: Classes WP-S, WP-W, WP-WX, and WP-WU. The material for fittings shall consist of forgings, bars, plates, or seamless or welded tubular products. The steel shall be melted by electric furnace, vacuum furnace, or electric furnace followed by vacuum or electroslag-consumable remelting. Forging or shaping operations shall be performed by hammering, pressing, piercing, extruding, upsetting, rolling, bending, fusion welding, machining or by combination of two or more of these operations. The materials shall undergo heat treatment and shall follow the required cooling process and tempering temperature. Chemical and product analyses shall be performed and shall conform to the required chemical composition in carbon, manganese, phosphorus, silicon, sulfur, nickel, chromium, molybdenum, copper, nitrogen, and titanium. The mechanical properties of the fitting material shall conform to the required values in yield strength, tensile strength, elongation, and hardness.
Materials of Pipe & Pipe Fittings
| Titanium | Grades 1, 2, 5, 7, 9 and 12 |
| Duplex | UNS S31803 & S32205 |
| Super Duplex | UNS S32750 & S32760 |
| 6 Moly | UNS S31254, N08925 & N08926 |
| Copper Nickel | UNS C70600 C70620 C7060X C7150 C71520 C71640 |
Duplex 2205 Chemical Composition
| C | 1 |
| N | 0.03 |
| P | 0.02 |
| Si | 2 |
| Mn | 3.0 – 3.5 |
| Mo | 22.0 – 23.0 |
| Fe | 0.03 |
| Cr | 4.5 – 6.5 |
| S | 0.14 – 0.2 |
| Ni | Bal |
Duplex 2205 Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15% |
Duplex 2205 Fittings Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| ASTM A815 WP-S | 1.4462 | S32205 |
ASME B16.9 S32205 Duplex Pipe Fittings Dimensions
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | ELBOWS AND TEES | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | 180 DEG RETURN BENDS | REDUCERS | CAPS |
| NPS | O.D. at Bevel (1), (2) | I.D. at End | Centre -to- End Dimension A, B, C, M | Centre-to- Centre O | Back-to- Face K | Alignment of Ends U | Overall Length H | Overall Length E |
| (1), (3), (4) | ||||||||
| 1/2 to 2.1/2 | 0.06 | 0.03 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| -0.03 | ||||||||
| 3 to 3.1/2 | 0.06 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 | 0.06 | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| -0.06 | ||||||||
| 10 to 18 | 0.16 | 0.12 | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| -0.12 | ||||||||
| 20 to 24 | 0.25 | 0.19 | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| -0.19 | ||||||||
| 26 to 30 | 0.25 | 0.19 | 0.12 | … | … | … | 0.19 | 0.38 |
| -0.19 | ||||||||
| 32 to 48 | 0.25 | 0.19 | 0.19 | … | … | … | 0.19 | 0.38 |
| -0.19 |
