ASTM A213 TP347H Stainless Steel Seamless Tube High Temperature Application

ASTM A213 TP347H Stainless Steel Seamless Tube High Temperature Application

ASTM A213 TP347H Stainless Steel Seamless Tube High Temperature Application
video
ASTM A213 TP347H Stainless Steel Seamless Tube High Temperature Application
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A213 TP347H
Payment & Shipping Terms:
Minimum Order Quantity: 100 KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1500 Tons Per Month
Contact Now
Detailed Product Description
Steel Grade: 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series Type: Seamless, Welded, Round Pipe/Tube
Standard: ASTM, AISI, GB, DIN, JIS Certification: ISO, SGS, BV, ISO & SGS, ISO/CE/SGS
Length: 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m Thickness: 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm
Technique: Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them Product Name: Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube
Outer Diameter: 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm Surface: Annealing, 8K, Polishing Or Unpolishing, Morror/Satin
Finish: Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright
High Light:

Stainless Steel Seamless Tube High Temperature

,

TP347H Steel Seamless Pipe

,

Annealing Stainless Steel Round Tube

ASTM A213 TP347H Stainless Steel Seamless Tube High Temperature Application

Alloy 347 (UNS S34700) is a columbium-stabilized austenitic stainless steel plate with good general corrosion resistance and slightly better resistance in strongly oxidizing conditions than 321 (UNS S32100). It has excellent resistance to intergranular corrosion after exposure to temperatures in the chromium carbide precipitation range of 800 – 1500°F (427 – 816°C). This alloy has good oxidation resistance and creep strength at 1500°F (816°C). It also has good low temperature toughness.

Alloy 347H (UNS S3409) stainless steel plate is a high carbon (0.04 – 0.10) version of the alloy. It was developed for increased creep resistance and strength at temperatures above 1000°F (537°C). In most cases, the carbon content of the sheet can be double certified.

Alloy 347 stainless steel plate cannot be hardened by heat treatment, only by cold working. It can be easily welded and machined through standard shop fabrication practices.



ASTM A213 TP347H Stainless Steel Seamless Pipes Range

ASTM A213 TP347H Stainless Steel Seamless Pipes Specification ASTM A269, ASTM A213, ASTM A312, ASME SA269, ASME SA213, ASME SA312
ASTM A213 TP347H Stainless Steel Seamless Pipes Grades 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC.
ASTM A213 TP347H Stainless Steel Seamless Pipes Type Seamless / Welded / ERW / EFW / Cold Draw / Hot Finish / Cold Finish
ASTM A213 TP347H Stainless Steel Seamless Pipes Outer Diameter Size Seamless - 1/2" NB TO 18" NB
Welded / ERW- 1" NB TO 16" NB
EFW - 8" NB TO 110" NB
ASTM A213 TP347H Stainless Steel Seamless Pipes Wall Thickness Schedule 10 to Schedule 160 (3 mm to 100 mm Thickness)
ASTM A213 TP347H Stainless Steel Seamless Pipes Length 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size.
ASTM A213 TP347H Stainless Steel Seamless Pipes Ends Plain Ends / Beveled Ends
ASTM A213 TP347H Stainless Steel Seamless Pipes Delivery Conditions As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw
ASTM A213 TP347H Stainless Steel Seamless Pipes Coating Electropolish, Mechanical Polish, Satin Finish, Passivated
ASTM A213 TP347H Stainless Steel Seamless Pipes Other Testing Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiograph HIC Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc
ASTM A213 TP347H Stainless Steel Seamless Pipes Dimension All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM And ASME
ASTM A213 TP347H Stainless Steel Seamless Pipes Value Added Services Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment / Annealed / Bright Annealed
ASTM A213 TP347H Stainless Steel Seamless Pipes Packaging Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
ASTM A213 TP347H Stainless Steel Seamless Pipes Shipment & Transportation By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes
ASTM A213 TP347H Stainless Steel Seamless Pipes Material Test Certificate Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC

Chemical Composition of ASTM A213 TP347H Stainless Steel Seamless Pipes

The chemical composition of grade 347 Stainless Steel is outlined in the following table

Element 347 347H
Chromium 17.00 min.-19.00 max. 17.00 min.-19.00 max.
Nickel 9.00 min.-13.00 max. 9.00 min.-13.00 max.
Carbon 0.08 0.04 min.-0.10 max.
Manganese 2.00 2.00
Phosphorus 0.045 0.045
Sulfur 0.03 0.03
Silicon 0.75 0.75
Columbium & Tantalum 10 x (C + N) min.-1.00 max. 8 x (C + N) min.-1.00 max.
Iron Balance Balance

Mechanical Properties of ASTM A213 TP347H Stainless Steel Seamless Pipes

The Mechanical Properties of grade 347H Stainless Steel Typical Values at 68°F (20°C) are displayed in the following table.

Yield Strength
0.2% Offset
Ultimate Tensile
Strength
Elongation
in 2 in.
Hardness
psi (min.) (MPa) psi (min.) (MPa) % (min.) (max.)
30,000 205 75,000 515 40 201 Brinell

ASTM A213 TP347H Stainless Steel Seamless Pipes Physical Properties

Physical properties of 347H grade stainless steel in the annealed condition

Properties Metric
Density 7.96 g/cm3

grade Specification Comparison for ASTM A213 TP347H Stainless Steel Seamless Pipes

Grade specifications for 347 grade stainless steel

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
321 S32100 321S31 58B, 58C 1.4541 X6CrNiTi18-10 2337 SUS 321
321H S32109 321S51 - 1.4878 X10CrNiTi18-10 - SUS 321H
347 S34700 347S31 58G 1.4550 X6CrNiNb18-10 2338 SUS 347



Application:

  • Food processing equipment, especially beer brewing, milk processing and winemaking.
  • Kitchen benches, sinks, sinks, appliances and appliances
  • Architectural Panels, Railings and Trim
  • Chemical containers, including shipping containers
  • heat exchanger
  • Woven or Welded Screens for Mining, Quarrying and Water Filtration
  • threaded fasteners
  • spring
  • other
