ASTM B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers

ASTM B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers

  • ASTM  B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers
  • ASTM  B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers
  • ASTM  B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers
  • ASTM  B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers
ASTM  B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B111 C70600-O61 Low Finned Tube
Payment & Shipping Terms:
Minimum Order Quantity: 300KGS
Price: NEGOTIABLE
Packaging Details: PLY-WOODEN CASE PACKING/IRON CASE PACKING
Delivery Time: Depends on quantity
Payment Terms: L/C, T/T
Supply Ability: ACCORDING TO CLIENT'S REQUIREMENT
Contact Now
Detailed Product Description
Product Name: Copper Nickel Alloy Low Finned Tube Standard: ASTM B111
Material: Copper/Carbon Steel/Stainless Steel/Aluminum Application: Oil Cooler
Type: Low Finned Tube
High Light:

Copper Nickel Alloy Low Finned Tube

,

ASTM B111 Low Finned Tube

,

Finned Nickel Alloy Tube

ASTM B111 C70600-O61 Copper Nickel Alloy Low Finned Tube For Heat Exchangers



Low Finned tube is a finned tube obtained through plastic cold deformation. The method consists in realizing, from a smooth tube, fins with a particular geometric form without removing material; this plastic deformation causes an increment of heat exchange efficiency, and allows to reduce the heat exchanger size.





According to user needs, we can produce all kinds of steel strip winding finned tube and steel aluminum composite finned tube. As the heat transfer element finned tube works long-term in high temperature and flue gas condition, such as finned tube in the boiler heat exchanger which use conditions are as high temperature and high pressure and corrosive atmosphere, should have a high performance metrics and they are as follows:Anti-corrosion ,Anti-wear,lower contact resistance ,Higher Stability,Anti-dust stratification.



This intergral low finned tubes are widely used as heat transfer tubes because of their large external surface area and high heat transfer performance compared with a plain tube. This enhanced surface fin tubes allow our customers to either reduce the size of the heat exchanger or increase its perfornance. The low finned tubes we manufacture are designed to meet the most efficient and durable thermal performance for the most challenging situations and long lasting service life.





Temper Tensile Str. Yield Str. Elong. Rockwell
B C F 30T
H55 414MPa (60ksi) 393MPa (57ksi) 10% 72 - 100 70
OS025 303MPa (44ksi) 110MPa (16ksi) 42% 15 - 65 26



Chemical composition of UNS C70600

Elements Content (%)
Nickel, Ni 9.0-11.0
Iron, Fe 1.0-1.8
Zinc, Zn 1.0
Manganese, Mn 1.0
Lead, Pb 0.05
Copper, Cu Remainder



Equivalent materials to UNS C70600

ASME SB111 ASME SB171 ASME SB359 ASME SB466 ASME SB467
ASME SB395 ASME SB543 ASTM B111 ASTM B151 ASTM B122
ASTM B171 ASTM B359 ASTM B395 ASTM B432 ASTM B466
ASTM B469 ASTM B543 ASTM B608 DIN 2.0872 MIL C-15726
MIL T-15005 MIL T-16420 MIL T-22214 SAE J461 SAE J463



Applications:

  • Heating systems
  • Ventilation systems
  • Refrigeration and climate control systems
  • Mechanical engineering
  • Automotive manufacturing
  • Chemicals and pertrochemical and power plant technology
