ASME SA213 Seamless T12 HF Welding Finned Tube for Radiadores

ASME SA213 Seamless T12 HF Welding Finned Tube for Radiadores

YUHONG Group can handle kinds of industry projects and supply variety of welding fin tubes in the industry. All of our products are domestically sourced, developed, and produced, that means our customers have immediate access to exactly the products they need for their particular application. What´s more, and we can make sure that you can get products with highest quality and manufacturing standards and a local, concerned, customer service presence.

This page is about ASME SA213 TP12 High Frequency Welded(HFW Fin Tube), it also called solid type fin tube,use steel or stainless steel strip or steel round bar/rod directly welded on the pipe /tube surface. And HFW fin tube can improving heat transfer efficiency much more than bare tube. Due to the welding tightly of the fins to the base pipe / tube, these finned tubes can be often used in vibrating conditions.

HFW Fin tube has many types: Serrated Fin Tube , Flat Fin Tube, Studded Fin Tube .And they are used in many different industries. They can use at very high temperatures possible because the strong connection between fin and base tube prevents loosening of fin because of heat stress, oxidization, corrosion etc. We YUHONG sell these fin tubes more than 33 years and sell in over 70 countries.

General Specifications  Fin Tubes

Base pipe O.D: 15.88-219.1mm
Fin height: 6-50mm
Fin thickness: 0.3-3.0mm
Fin pitch: as customer's request.
End: Plain Ends, Beveled Ends
No fin area on both side: As Customer's request and drawing

Specifications For Various Types Of Finned Tubes

Base pipe / tube Material :

1.Stainless steel: ASME SA213/ASTM A213, ASME SA249/A249 ,ASME SA312/A312

( TP304,304L, TP304H, TP310S, TP310H, TP316L, TP316H, TP316Ti, TP317, TP317L, TP321,TP321H, TP347, TP347H, TP904L )

2.Duplex/Super Duplex Steel: ASME SA789/A789 , ASME SA790/A790

( S31803, S32205, S32750, S31500, S32304, S32900 )

3.Carbon Steel: ASME SA106/ASTM A106 Gr B, Gr C, ASME SA179/ASTM A179, ASME SA192/ASTM A192, ASTM A214, ASTM A210 Gr.A1, Gr.C.

4.Alloy Steel:

ASME SA213/ASTM A213 T1, T11, T12, T22, T23, T5, T9, T91, T92 ;

ASME SA335 /ASTM A335 P1, P11, P12, P22, P23, P5, P9 , P91, P92 , 16Mo3, 15Mo3, 13CrMo-4, 12Cr1MoVG

5.Nickel Alloy Steel: Hestalloy / Inconel /  Pure Nickel / NS Alloy / Copper Alloy Steel

Fin material: Alloy Steel , Stainless Steel , Carbon Steel

Features Of Finned Tube

•  High-performance
•  Easy installation
•  Easy installation
•  Less space required
•  Optimized surface
•  Finest technology used
•  Less energy consumption
•  Increased reliability
•  Low maintenance
•  High mechanical resistance
•  Compact design,etc

Detailes Of ASME SA213 Tube

ASME SA213  This specification covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes, designated Grades T5, TP304, etc. Used for  boiler, superheater, heat exchanger, or condenser tubes and other application.

Chemical Composition (%)--MAX K11562

Mechanical Properties K11562

Inspections and Tests

Related Industries Involved

1.Oil / Petroleum Industry​

2.Metallurgical industry

3.Power industry

4.Light industry

5.Pharmaceutical industry

6.Food industry

7.Chemical industry

Application

1.Boilers (Calderas)

2.Economizers

3.Fin tubes

4.Waste Heat Recovery

5.Air Coolers / Oil Coolers / Hydrogen Coolers / Generator Coolers

6.Air Perheaters / Air Cooling Heat Exchanger / Super Heaters / Fired heaters / HRSG

7.Heat Pipe Technology

For a rapid quotation, pls send with following requirement:

1.Number of Pieces.

2.Base Tube: Diameter, thickness, length and material specification.

3.Fins: material specification, type (solid or serrated), height, thickness, spacing, finned length and unfinned sections. Weld prep details if required.

4.Delivery period required.
