HFW Solid Finned Tube, also known as high frequency welded helical solid finned tube, is a type of spiral finned tube that offers high thermal efficiency and a compact design solution for various heat exchangers utilizing clean flue gas. The two types of spiral finned tubes are solid type and serrated type.

Helical solid finned tubes are manufactured by helically wrapping a continuous strip of fins around the tube and welding it continuously using high frequency resistance welding at a frequency of 400 kHz. This ensures a strong contact between the fin tape and the surface of the base tube. The welding process takes place at the root of the helix, where the fin strip bends around the diameter of the tube.

To determine the required heat transfer surface area per unit length of tube, specifications such as fin height, fin thickness, and/or number of fins per meter of length need to be provided for a given tube or pipe size.

The HFW Solid Finned Tube configuration is suitable for various heat exchanger applications, particularly those involving high temperatures and high pressures. It offers efficient and reliable bonding between the fin and the tube, allowing it to withstand high temperatures on the fin side under all temperature and pressure conditions.

Technical details of the base tube include a pipe diameter range of 20mm to 219mm, tube thickness ranging from 2mm to 16mm, and materials such as carbon steel, stainless steel, alloy steel, weathering steel, duplex steel, super duplex steel, inconel, high chromium high nickel and chromium alloys, CK 20 material, and others.

Regarding the fin details, the fin thickness ranges from 0.8mm to 4mm, fin height ranges from 0.25" (6.35mm) to 1.5" (38mm), and fin density ranges from 43 fins per meter to 287 fins per meter. The materials used for fins are carbon steel, stainless steel, alloy steel, weathering steel, duplex steel, and incolloy.

To receive a rapid quotation, please provide the following information: number of pieces, base tube specifications including diameter, thickness, length, and material; fin specifications including material, type (solid or serrated), height, thickness, spacing, finned length, and unfinned sections; and any required weld prep details. Additionally, specify the desired delivery period.
