Low Fin Tube, ASME SA179 Seamless Base Tube, Cost-Effective for Feedwater Heaters

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, CCS, ISO 9001-2008
Model Number:	Low Fin Tube, Low Finned Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500kgs
Price:	Negotiable
Packaging Details:	Iron Frame Case with end cap
Delivery Time:	Depending on QTY
Payment Terms:	T/T, L/C AT SIGHT
Supply Ability:	50000 PCS PER MONTH

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Fin Type:	Low Fin Tube , Low Finned Tube , Thread Fin Tube	Fin Height:	<1.6mm
Fin Pitch:	0.6-2mm	Fin Thickness:	Around 0.3mm
Fin Material:	Same As Base Tube (SS,AS,CS,Copper Etc.)	Application:	Air Cooler, Cooling Tower , Oil Refininging
Highlight:	power plants Heat Exchanger Finned Tube , A179 Finned Tube , Sa179 Finned Tube

Low Fin Tube, ASME SA179 Seamless Base Tube, Cost-Effective for Feedwater Heaters

ASTM A179,ASME SA179 cold-drawn seamless steel tube Chemical Composition

Material	Chemical Composition(%)
Material	C	Si	Mn	P	S
ASTM A179	0.06-0.18	≤ 0.25	0.27-0.63	≤0.035	≤0.035

ASTM A179,ASME SA179 cold-drawn seamless steel tube Mechanical Propertie

Grade	ASTM A179
Tensile Strength(MPa)	≥325
Yield Strength(MPa)	≥180
Elongation,%	≥35
Hardness, HRB	≤72

ASTM A179,ASME SA179 Tube Wall Thickness Tolerance

Outside Diameter In. (mm)	Wall thickness Tolerance %
Outside Diameter In. (mm)	Over (+)	Under (-)
1 ½ (38.1) and under	20	0
Over 1½ (38.1)	22	0

ASTM A179,ASME SA179 Tube Outside Diameter Tolerance

Outside Diameter In. (mm)	Permissible Variations In. (mm)
Outside Diameter In. (mm)	Over (+)	Under (-)
Under 1 (25.4)	0.004 (0.1)	0.004 (0.1)
1 to 1 ½ (25.4 to 38.1), Incl	0.006 (0.15)	0.006 (0.15)
Over 11⁄2 to 2 [38.1 to 50.8], Excl	0.008 (0.2)	0.008 (0.2)
2 to 21⁄2 [50.8 to 63.5], Excl	0.010 (0.25)	0.010 (0.25)
21⁄2 to 3 [63.5 to 76.2], Excl	0.012 (0.3)	0.012 (0.3)

ASTM A179,ASME SA179 Length Tolerance

Outside Diameter	Cut Length, in.(mm)
In.(mm)	Over (+)	Under (-)
All Sizes	3⁄16 [5]	0 [0]
Under 2 [50.8]	1⁄8 [3]	0 [0]
2 [50.8] and over	3⁄16 [5]	0 [0]
Under 2 [50.8]	1⁄8 [3]	0 [0]
2 [50.8] and over	3⁄16 [5]	0 [0]
These permissible variations in length apply to tubes before bending. They apply to cut lengths up to and including 24 ft [7.3 m]. For lengths greater than 24 ft [7.3 m], the above over-tolerances shall be increased by 1⁄8 in. [3 mm] for each 10 ft [3 m] or fraction thereof over 24 ft or 1⁄2 in. [13 mm], whichever is the lesser.

Feel free to provide the following details for the finned tube offer:

Base tube material:
Base tube size (OD x WT x Length):
Fin material:
Fin type:
Fin diameter or height:
Fin thickness:
Fins per inch, meter, or fin pitch:
Length of plain, unfinned ends:
Finned Tube Quantity:
Any additional fabrication requirements (e.g., bending, welding into tubeplate, assembly):
