Finned Tube ASME SA213 SMLS T12 Stainless Steel Tube HFW Carbon Steel Fins for Air Preheater

Product Details:

Place of Origin:	CHINA
Brand Name:	YuHong
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	TP304 T12

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T
Supply Ability:	ACCORDING TO CUSTOMER'S REQUEST

Contact Now

All Products

Stainless Steel Seamless Pipe (286)

Stainless Steel Seamless Tube (275)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (28)

Needle Tube (102)

Fin Tube (619)

Heat Exchanger (16)

Heat Exchanger Tube (425)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (78)

Copper Alloy Tube (222)

Alloy Steel Tube (182)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (141)

Steel Fitting (797)

Steel Flange (583)

Others (388)

Cladding Parts (7)

Detailed Product Description

BRAND:	YH,YHSS,YUHONG	OD:	20mm OD Min To 219mm OD Max.
Fin Height:	6-50mm	Fin Thickness:	0.3-0.5mm
Fin Spacing:	According To Customer Requirements.	End:	Flat End, Bevel End
FIN MATERAIL:	T12	TUBE MATERIAL:	TP304,TP304L,TP316L,TP317L,TP321,TP310S
Highlight:	Carbon Steel Fins Finned Tube , Air Preheater Finned Tube , ASME SA213 Finned Tube

Finned Tube ASME SA213 SMLS T12 Stainless Steel Tube HFW Carbon Steel Fins for Air Preheater

High-frequency welded finned tube is a kind of finned tube, which is mainly welded by high-frequency welding and is a new type of excellent heat dissipation element. High-frequency welded finned tube is welded by high-frequency current, with reliable welding method, excellent performance, small weld seam, and more solid and beautiful radiator surface.

High-frequency welded finned tube is a commonly used heat dissipation element in finned tube radiator. Welding high-frequency welded finned tube on the base tube of the radiator can improve the heat transfer coefficient of the heat exchanger side of the radiator and enhance the heat dissipation effect of the radiator, and the excellent heat dissipation effect makes the finned tube more and more popular.

High-frequency welded finned tubes are welded with high-frequency current, which can increase the compactness of the radiator and improve the ety of the high-frequency welded finned tube radiator during operation. High-frequency welding process is an improved and upgraded process on the basis of the basic welding process, and it is also a better welding process.

The better the welding process used for high-frequency welded finned tube, the faster the welding speed, the narrower the weld seam, the more beautiful the appearance of the radiator. The appearance of high-frequency welded finned tube is simple and generous, mainly in silver and grey.

Equivalent steel grade

Standard	Grade
ASTM A213	T12
GB5310	15CrMoG

Chemical Composition of ASTM A213 T12

Grade	Chemical Composition(%)
Grade	C	Mn	P	S	Si	Cr	Mo
A213 T12	0.05-0.15	0.30-0.60	≤0.025	≤0.025	≤0.50	0.80-1.25	0.45-0.65

Mechanical Properties of ASTM A213 T12

Low Alloy Steels
Grade	UNS Designation	Tensile Strength, min, ksi [MPa]	Yield Strength, min, ksi [MPa]	Elongation in 2 in. or 50 mm, min, %	Hardness
					Brinell/Vickers	Rockwell
T12	K11562	60 [415]	32 [220]	30	163 HBW/ 170 HV	85 HRB

Base Tube Details

Tube Diameter : 20 mm OD Min to 219 mm OD Max.

Tube Thickness : Minimum 2 mm up to 16mm

Tube Material : Carbon Steel, Stainless Steel, Alloy Steel, Corten steel, duplex Steel, Super Duplex Steel, Inconel, High Chrome High Nickle & Incolloy, CK 20 material and some other material.

Fin material

Alloy steel, Stainless steel High Frequency Welded fins tube, carbon steel High Frequency Welded fins tube Duplex High Frequency Welded fins tube super duplex High Frequency Welded fins tube Air cooler fins tube, Air preheater fins tube.

Extruded fins tube, Serrated fin tubes, L Type fins tube, G Type fins tube, LL Type fins tube, H Type fins tube, KL Type fins tube, HFW fin tube laser welded fin tube.
