ASME SA179 Fin Tube Embedded Type With A1060 Aluminum Fins Pull Test Pass

Product Details:

Place of Origin:	China
Brand Name:	Yuhong boiler tube
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008.
Model Number:	ASTM A210 Gr A1 Seamless Medium Carbon-Molybdenum Alloy Steel Boiler

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap etc.
Delivery Time:	20-80
Payment Terms:	L/C, T/T
Supply Ability:	800 Tons/ month

Contact Now

All Products

Stainless Steel Seamless Pipe (278)

Stainless Steel Seamless Tube (267)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (91)

Fin Tube (605)

Heat Exchanger (10)

Heat Exchanger Tube (421)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (75)

Copper Alloy Tube (211)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (787)

Steel Flange (576)

Others (384)

Detailed Product Description

Standard:	ASME SA179	Type:	Embedded Type
Material:	SA179	Tube Thickness:	2.77mm
Tube OD:	25.4mm	Fin Height:	15.8mm
Fin Thickness:	2.3mm ±0.2mm
Highlight:	Embedded Type Fin Tube , ASME SA179 Fin Tube , A1060 Aluminum Fins Fin Tube

ASME SA179 Fin Tube Embedded Type with A1060 Aluminum Fins Pull Test Pass

Yuhong Holding Group Co., Ltd. is a leading manufacturer of finned tubes with over 20 years of export experience. We have successfully delivered our products to 80 countries and are ranked among the top five exporters of finned tubes in China. With 55 production lines and a dedicated workforce of over 110 employees, our manufacturing facility spans an impressive 20,000 square meters. We pride ourselves on utilizing advanced production technologies and equipment to ensure the highest quality in our products and services.

Product Overview: ASME SA179 Fin Tube with A1060 Aluminum Fins

The ASME SA179 fin tube with A1060 aluminum fins is engineered for optimal thermal performance and durability. This product is designed to meet the stringent requirements of various industrial applications, providing exceptional heat transfer efficiency.

Material Properties:

Material	Specification	Properties
SA179	Carbon Steel	Excellent mechanical properties and high pressure tolerance
A1060	Aluminum	Lightweight, corrosion-resistant, and excellent thermal conductivity

A1060 Aluminum Fins

The A1060 aluminum fins are specifically chosen for their superior performance characteristics. With a thermal conductivity of approximately 235 W/m·K, they enhance the overall heat exchange efficiency of the fin tube. This makes them ideal for applications requiring effective heat dissipation.

Fin Performance:

Property	Value
Thermal Conductivity	235 W/m·K
Corrosion Resistance	Excellent
Weight	Lightweight

Pull Test Success

Rigorous testing has confirmed that our fin tubes pass the pull test, ensuring that the fins remain securely attached under high-stress conditions. This quality assurance is a testament to our commitment to providing reliable and durable products.

Product: ASME SA179 Fin Tube Embedded Type with A1060 Aluminum Fins

Test Specification	Details
Tube End Requirements	Free from burrs, weld buildup, and discontinuities inside and outside.
Fin Interruptions	Not more than 2 interruptions per tube, with adjacent fin ends connected by stapling.
Loose Fins Limit	Total number of loose fins shall not exceed six per interruption.
Groove Checks	Regular checks of groove depth and minimum wall thickness during production.
Pull Test Requirement	Finned tubes shall be subjected to a pull test if specified by the contractor.
Testing Frequency	One out of every 100 tubes tested at two points no less than 3m apart.
Fin Cutting Requirement	Fin shall be cut leaving a pie-shaped section with a root length of approximately 12mm.
Weight Application for Testing	Clamp section and apply weights up to 2.3kg for at least one minute.
Failure Protocol	If a tube fails, test a location within 0.9m. If it fails again, test another tube from the lot.
Lot Acceptance Criteria	If the second tube fails, the entire lot of 100 tubes shall be rejected.

Applications

The wrapped fin tube is widely used in various industries, including:

Power Generation: Enhancing efficiency in heat exchangers and condensers.
Chemical Processing: Providing reliable heat transfer in reactors and evaporators.
HVAC Systems: Ensuring effective temperature control in heating and cooling applications.

In conclusion, Yuhong Holding Group Co., Ltd. stands at the forefront of the fin tube industry, delivering innovative solutions backed by two decades of experience. Our ASME SA179 fin tube with A1060 aluminum fins exemplifies our commitment to quality and performance, making it a reliable choice for diverse industrial applications.
