ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler

ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler

  • ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler
  • ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler
  • ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler
  • ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler
ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler
Product Details:
Place of Origin: Chiana
Brand Name: Yuhong
Certification: ABS, BV, DNV, LR,
Model Number: ASTM A213 T5
Payment & Shipping Terms:
Minimum Order Quantity: 100=
Price: Negotiaean;e
Packaging Details: ply-wooden case with iron frame, plastic woven bags, bundle
Delivery Time: 7DAYS
Payment Terms: T/T,L/C
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Finned Pitch: 1.5mm-25mm Fin Height: 5mm-30mm
Tube Standard: ASTM A213 / ASME SA213 Item: Main Heat Exchanger
Production Name: G Fin Tube Design Temperature: Below 450℃
Loading Port: Ningbo Port, Shanghai Port Type: Straight
Highlight:

Al1060 Fin Strip Fin Tube

,

Air Cooler Fin Tube

,

Air Cooler Alloy Steel Seamless Tube

ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler


This product is a high-efficiency finned heat exchanger tube, engineered for use in air-cooled heat exchangers and thermal recovery systems. It integrates a seamless ASTM A213 T5 alloy steel tube with precision-wound or embedded Al1060 aluminum fins, optimizing thermal performance in high-temperature, corrosive environments like power plants, petrochemical plants, and refineries.

Product Overview

  • Base Tube Material: ASTM A213 T5 — a chromium-molybdenum alloy steel with strong creep strength and oxidation resistance at elevated temperatures.

  • Fin Type: Embedded (G-type) or wound (as per requirement).

  • Fin Material: Aluminum Strip Al1060 — highly conductive, lightweight, and corrosion-resistant.

  • Fin Attachment: Mechanical tension winding or embedding ensures secure bonding and excellent thermal contact.

ASTM A213 T5 Alloy Steel G Fin Tube– Chemical Composition

Element Content (%)
C 0.15 max
Mn 0.30 – 0.60
P 0.025 max
S 0.025 max
Si 0.50 max
Cr 4.00 – 6.00
Mo 0.45 – 0.65



Al1060 (Aluminum Fin Strip) – Chemical Composition

Element Content (%)
Al ≥ 99.60
Si ≤ 0.25
Fe ≤ 0.35
Cu ≤ 0.05
Mn ≤ 0.03
Mg ≤ 0.03
Zn ≤ 0.05
Ti ≤ 0.03


Material Properties

▶ ASTM A213 T5 Base Tube:

Property Value
Tensile Strength ≥ 415 MPa
Yield Strength ≥ 205 MPa
Elongation ≥ 30%
Cr Content 4.00 – 6.00%
Mo Content 0.45 – 0.65%

▶ Aluminum Fin – Al1060:

Property Value
Al Content ≥ 99.6%
Thermal Conductivity ~237 W/m·K
Tensile Strength 60 – 100 MPa
Elongation ≥ 25%


Key Advantages

  • High Heat Transfer Efficiency: Thanks to tight mechanical bonding and high thermal conductivity fins.

  • Excellent Oxidation Resistance: T5 alloy resists scaling and creep at elevated temperatures.

  • Corrosion Performance: Al1060 fins offer strong protection against environmental corrosion.

  • Durability: Reliable under thermal cycling and vibration due to secure fin attachment.

Applications

  • Air-cooled heat exchangers in refineries and chemical plants

  • Waste heat recovery systems

  • Gas cooling and economizers

  • Oil & gas processing units

  • Natural draft air coolers

ASTM A213 T5 Alloy Steel Seamless Tube With Al1060 Fin Strip Fin Tube For Air Cooler 0
