Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler

Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler

  • Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler
  • Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler
  • Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler
  • Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler
Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler
Product Details:
Place of Origin: China
Brand Name: Yuhong
Certification: ABS, BV, CCS, DNV, LR,
Model Number: ASTM A179
Payment & Shipping Terms:
Minimum Order Quantity: 100kgs
Price: Negotiable
Packaging Details: PLy-Woonden case wth iron frame
Delivery Time: 7DAYS
Payment Terms: L/C,T/T
Contact Now
All Products
Stainless Steel Seamless Pipe (286)
Stainless Steel Seamless Tube (275)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (28)
Needle Tube (102)
Fin Tube (619)
Heat Exchanger (16)
Heat Exchanger Tube (425)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (112)
Nickel Alloy Pipe (259)
Nickel Alloy Tube (78)
Copper Alloy Tube (222)
Alloy Steel Tube (182)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (141)
Steel Fitting (797)
Steel Flange (583)
Others (388)
Cladding Parts (7)
Detailed Product Description
Fin Tube Packing: Ply-wooden Case With Iron Frame Ndt: MT, ET, UT, HT, PT, PMI
Product: Fin Tube Bare Length: 50mm/50mm
Design Temperature: Below 450℃ Carbon Steel: ASME SA192, ASME SA210 GR.A1
Highlight:

Air Cooler Fin Tube ASTMA179

,

Carbon Fin Tube ASTM A179

,

Air Cooler Carbon Fin Tube

Carbon Steel Fin Tube ASTM A179  G Type, Embedded Fin Tube, For Air Cooler

Introduction

This G-Type Embedded Fin Tube is manufactured with a carbon steel seamless tube (ASTM A179) as the base and high-purity aluminum strip (Al1060) as the fin material. The G-type design features fins mechanically embedded into a groove cut in the base tube, offering superior mechanical bonding and enhanced heat transfer efficiency. It is ideal for air-cooled heat exchangers used in demanding industrial applications.


Chemical Composition

Base Tube – ASTM A179 (Carbon Steel)

Element C (max) Mn P (max) S (max)
Content (%) 0.06–0.18 0.27–0.63 0.035 0.035

Fin – Al1060 (Aluminum Strip)

Element Al (%) Si (%) Fe (%) Cu (%) Zn (%)
Content ≥99.6 ≤0.25 ≤0.35 ≤0.05 ≤0.05

Mechanical Properties

ASTM A179 Base Tube

Property Value
Tensile Strength ≥325 MPa
Yield Strength ≥180 MPa
Elongation ≥35%
Hardness ≤72 HBW


Advantages

  • Strong Fin Bonding: The G-type embedding method ensures fins are mechanically locked, preventing loosening under vibration or thermal cycling.

  • Excellent Heat Transfer: Increased surface area significantly boosts air-side heat exchange efficiency.

  • Corrosion Resistance: Aluminum fins protect against atmospheric corrosion, prolonging service life.

  • Long Lifespan: Ideal for high-dust and high-temperature environments like refineries or petrochemical plants.

  • Maintenance-Friendly: Fin integrity remains stable over long operation periods.

Applications

  • Air Coolers in:

    • Petrochemical Plants

    • Oil Refineries

    • Power Generation Facilities

    • Offshore Platforms

    • Gas Processing Plants

Carbon Steel ASTM A179 G Type Embedded Fin Tube For Air Cooler 0
