ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System

ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System

  • ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System
  • ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System
  • ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System
  • ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System
ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System
Product Details:
Place of Origin: China
Brand Name: Yuhong
Certification: ABS, BV, ISO, ASTM, SGS
Model Number: ASME SA335 P22
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with Plastic Cap
Delivery Time: 7-45DAYS
Payment Terms: L/C, T/T
Supply Ability: 1000 ton/month
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Fin Grade: 11-13CR Ndt: HT, ET, UT , PT
Product Type: HFW Finned Tube Bare Tube: ASTM A335 P22
Fin Thickness Tolerance: Customized Pipe End: Plain End, Beveled End
Highlight:

ASME SA335 P22 alloy steel seamless pipe

,

HFW solid fin tube for HRSG

,

alloy steel fin tube with warranty

ASME SA335 P22 Alloy Steel Seamless Pipe HFW Solid Fin Tube For HRSG System



Product Description


ASME SA335 P22 alloy steel seamless pipe with HFW (High-Frequency Welding) solid fins is a high-performance component designed for Heat Recovery Steam Generator (HRSG) systems in power plants. The P22 grade, containing chromium and molybdenum, provides excellent creep resistance, high-temperature strength, and improved oxidation resistance. The solid fin design enhances heat transfer efficiency while maintaining structural integrity under extreme service conditions.

Chemical Composition (ASME SA335 P22)

Element C (max) Mn P (max) S (max) Si Cr Mo
Content (%) 0.05–0.15 0.30–0.60 0.025 0.025 0.50–1.00 1.90–2.60 0.87–1.13

Mechanical Properties (ASME SA335 P22)

Property Requirement
Tensile Strength ≥ 415 MPa
Yield Strength ≥ 205 MPa
Elongation ≥ 30%
Hardness ≤ 163 HB



Applications

  • HRSG convection and evaporator sections

  • Waste heat recovery systems in power generation and petrochemical industries

  • High-temperature and high-pressure boilers

  • Economizers, superheaters, and reheaters

Advantages



  • Excellent high-temperature creep resistance

  • Strong corrosion and oxidation resistance in furnace environments

  • Long service life under cyclic thermal stresses

  • Enhanced heat transfer efficiency through solid fin configuration

  • Reliable performance in HRSG and other high-pressure boiler systems
