Name: ASTM A179 Carbon Steel Fin Tube Extruded Type With Al1060 For Fin Fan Cooler
Brand: Yuhong Group Co.,Ltd
SKU: ASTM A179
Price: 100,000.00 USD
Availability: InStock

Yuhong Holding Group Co.,LTD

English

Home

Products

About Us

Factory Tour

Quality Control

Company News

Home Products Fin Tube

ASTM A179 Carbon Steel Fin Tube Extruded Type With Al1060 For Fin Fan Cooler

Product Details:

Place of Origin:	China
Brand Name:	Yuhong
Certification:	DNV, BV, PED, LR, ABS, TS, CCS
Model Number:	ASTM A179

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with Plastic Cap
Payment Terms:	L/C, T/T
Supply Ability:	1000 ton/month

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Package:	Ply-woonden Case With Iron Case	Fin Grade:	Al 1060
Fin Height:	15.875mm	Base Tube Standard:	ASME SA179
Base Tube Length:	Customized	Product:	Fin Tube
Application:	Heat Exchanger, Air Cooler	Fin Type:	Extruded
Highlight:	ASTM A179 carbon steel fin tube , extruded fin tube for cooler , Al1060 fin fan cooler tube

ASTM A179 Carbon Steel Fin Tube Extruded Type With Al1060 For Fin Fan Cooler

Product Overview:
This fin tube consists of a seamless ASTM A179 carbon steel base tube with extruded Aluminium 1060 fins. The extrusion process forms an integral bond between the fins and the tube, ensuring excellent heat transfer performance, mechanical durability, and long-term reliability in air-cooled heat exchanger systems.

ASTM A192 / A192M : Seamless Carbon Steel Boiler Tubes for High-Pressure Service
ASTM A210 / A210M : Seamless Medium-Carbon Steel Boiler and Superheater Tubes
ASTM A179 / A179M : Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes

Tube Type:Seamless (Cold Drawn)
Ends:Plain ends or bevel ends.
Surface protection:black painting,anti-rust oil or varnish.

Detail:

General extrusion production capacity	General specifications of Extruded Fin Tubes/Embedded
Facility: 20 finning machines. Daily capacity up to 7600 meters. Extruded fins type: solid plain and serrated.	Tube OD: 12mm min.~50.8mm(2'') max. Tube Length: 32 meters max. Fin Height: 25.4 mm max. Fin Thickness: appr. 0.2/0.3/0.4mm/0.5mm/0.6mm Fin Pitch: 1.5mm min.

Chemical Composition ASTM A179 Carbon Steel (Base Tube)

Property	Content (wt%)
Carbon (C)	0.06 – 0.18
Manganese (Mn)	0.27 – 0.63
Phosphorus (P)	≤ 0.035
Sulfur (S)	≤ 0.035
Iron (Fe)	Balance

Aluminium 1060 (Fin Material)

Property	Content (wt%)
Aluminium (Al)	≥ 99.6
Copper (Cu)	≤ 0.05
Iron (Fe)	≤ 0.35
Silicon (Si)	≤ 0.25
Zinc (Zn)	≤ 0.05
Manganese (Mn)	≤ 0.03
Magnesium (Mg)	≤ 0.03
Titanium (Ti)	≤ 0.03
Others (Total)	≤ 0.15

Mechanical Properties ASTM A179 Carbon Steel (Base Tube)

Property	Value
Tensile Strength (MPa)	≥ 325
Yield Strength (MPa)	≥ 180
Elongation (%)	≥ 35

Aluminium 1060 (Fin Material)

Property	Value
Tensile Strength (MPa)	60 – 100
Yield Strength (MPa)	≥ 20
Elongation (%)	≥ 23
Brinell Hardness (HB)	~ 27

Applications

Fin Fan Coolers (Air Coolers) in refineries, petrochemical plants, and power plants
Air-cooled Heat Exchangers for oil, gas, and chemical industries
Process Cooling Systems in fertilizer, LNG, and hydrogen plants
Convection Cooling in power generation and industrial boilers

Advantages

Strong metallurgical bond between fins and tube, resistant to thermal cycling
High thermal conductivity from Aluminium 1060 fins
Robust carbon steel base tube (ASTM A179) for high strength and pressure resistance
Longer service life and easier cleaning compared with mechanical fin types (L/LL/KL/G)
Cost-effective solution for large-scale air cooling system
