Spiral Welded Finned Tubes with A106 Base Pipe CS Fins for Heat Exchangers

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	HFW FIN TUBE

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiable
Packaging Details:	IRON FRAME WOODEN CASE
Delivery Time:	Depends on quantity
Payment Terms:	L/C,T/T
Supply Ability:	1000 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (324)

Stainless Steel Seamless Tube (318)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (36)

Needle Tube (149)

Fin Tube (692)

Heat Exchanger (23)

Heat Exchanger Tube (456)

Heat Exchanger Tube Bundle (46)

Heat Exchanger Tubesheet (122)

Heat Exchanger Baffle (39)

Air Cooler (10)

Pressure Vessel (4)

Stainless Steel Welded Pipe (59)

Stainless Steel Welded Tube (127)

Nickel Alloy Pipe (270)

Nickel Alloy Tube (95)

Copper Alloy Tube (247)

Alloy Steel Tube (208)

Titanium Tube (18)

Bright Annealed Tube (171)

Boiler Tube (151)

Steel Fitting (852)

Steel Flange (650)

Others (404)

Cladding Parts (8)

Detailed Product Description

Base Tube Material Standard:

ASTM A106 Gr.B Seamless

Fin Attachment Method:

High-Frequency Welded (HFW)

Max Operating Temperature:

400°C

Fin Density Range:

150-250 Fins Per Meter

Highlight:

Spiral welded finned tubes for heat exchangers

A106 carbon steel finned tubes

CS fin tubes with spiral weld

High-Frequency Welded Finned Tubes: ASTM A106 Carbon Steel Base Tube + Carbon Steel (CS) Fins

1. Product Overview

High-frequency welded (HFW) finned tubes combine ASTM A106 Gr.B seamless carbon steel

base tubes with carbon steel fins using advanced solid-state welding technology. These tubes

deliver 8-10x higher heat transfer efficiency versus bare pipes, ideal for heat recovery systems,

boilers, and process heaters operating at ≤400°C.

2. Fin Tube Structure & Manufacturing Process

Component	Material	Key Process
Base Tube	ASTM A106 Gr.B	Seamless cold-drawn, OD 25.4-114.3mm
Fins	Carbon Steel (CS)	High-frequency welding (2,000 Hz), no filler
Bond Quality	Metallurgical fusion	100% ultrasonic tested, shear strength ≥35MPa

3. Chemical Composition (ASTM Standards)

Base Tube (A106 Gr.B):

Element	C	Mn	P (max)	S (max)	Si
%	≤0.30	0.29-1.06	0.035	0.035	≥0.10

Fins (Carbon Steel SPHC):

Element	C (max)	Mn (max)	P (max)	S (max)	Al (min)
%	0.12	0.50	0.040	0.040	0.020

4. Critical Dimensions & Tolerances

Parameter	Range/Tolerance	Standard
Base Tube OD	25.4 - 219 mm (±0.15mm)	ASTM A106
Fin Height (H)	5 - 30 mm (±0.5mm)	HEI Standards
Fin Thickness (T)	0.8 - 3.0 mm (±0.1mm)	Custom
Fin Pitch	4-25 (±0.2)	ASME B36.10M
Max Length	24 meters (straightness ≤1mm/m)	Custom

5. Performance Advantages

✅ Heat Transfer Coefficient: 45-65 W/m²K (vs. 5-8 W/m²K for bare tubes)

✅ Corrosion Resistance: Zinc/aluminized coating optional for acidic environments

✅ Pressure Rating: Up to 15 MPa at 350°C (ASME B31.1 compliant)

✅ Thermal Fatigue Life: >10,000 cycles (per ASTM E606)

6. Application-Specific Solutions

Industry	Use Case	Tube Configuration Example
Power Plants	Economizers, Air Preheaters	OD 50.8mm + 16mm fins @ 197 FPM
Petrochemical	Process Gas Heaters, Reactors	OD 76.2mm + 19mm fins @ 230 FPM
HVAC	Thermal Fluid Heaters, Dehumidifiers	OD 38.1mm + 12.7mm fins @ 180 FPM
Waste Heat Recovery	Exhaust Gas Boilers (≤550°C)	Aluminized coating + 25.4mm fins
