ASTM A312 TP304 Hollow Bars, With Thick Walls, Used To Manufacture Flanges And Machinery

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A312 TP304

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	NEGOTIABLE
Packaging Details:	according to client requirements/wooden case packing/Woven bag packing
Delivery Time:	5-80 DAYS
Payment Terms:	T/T, L/C
Supply Ability:	according to client requirements

Contact Now

All Products

Stainless Steel Seamless Pipe (331)

Stainless Steel Seamless Tube (322)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (36)

Needle Tube (156)

Fin Tube (703)

Heat Exchanger (28)

Heat Exchanger Tube (458)

Heat Exchanger Tube Bundle (49)

Heat Exchanger Tubesheet (125)

Heat Exchanger Baffle (39)

Air Cooler (11)

Pressure Vessel (4)

Stainless Steel Welded Pipe (61)

Stainless Steel Welded Tube (132)

Nickel Alloy Pipe (273)

Nickel Alloy Tube (101)

Copper Alloy Tube (250)

Alloy Steel Tube (210)

Titanium Tube (20)

Bright Annealed Tube (172)

Boiler Tube (152)

Steel Fitting (860)

Steel Flange (659)

Others (404)

Cladding Parts (8)

Detailed Product Description

Material:	TP304	Standard:	ASTM A312
Third Party Inspection:	BV,SGS,ASP	Application:	Construction, Automotive, Chemical Industry, Food Processing
Package:	Standard Export Package	Certificate:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Highlight:	ASTM A312 TP304 hollow bars , thick wall stainless steel bars , stainless steel bars for flanges

ASTM A312 TP304 Hollow Bars, With Thick Walls, Used To Manufacture Flanges And Machinery

Description

HOLLOW BAR represents the optimal form for flange production from round bars.

Flange/Forging Machining: When producing large-diameter flanges, using solid round bars directly requires drilling a huge hole, resulting in significant material waste and time consumption. Using HOLLOW BAR, the material is already close to its final shape, requiring only minimal internal and external turning, leading to high material utilization and low processing costs.

Large Sleeves/Machinery Parts: Used in manufacturing bearing rings, large hydraulic cylinder barrels, machine bushings, and other parts requiring high wall thickness and strength. The wall thickness is thicker than ordinary pipes, but not yet reaching the wall thickness level of typical hollow bars.

Chemical Composition (%)
Element	TP304
Carbon (C)	≤ 0.08
Manganese (Mn)	≤ 2.00
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.030
Silicon (Si)	≤ 1.00
Chromium (Cr)	18.0 – 20.0
Nickel (Ni)	8.0 – 11.0
Iron (Fe)	Balance

Mechanical Properties (Room Temperature)
Property	TP304
Tensile Strength, Rm (min)	515 MPa (75 ksi)
Yield Strength, Rp0.2 (min)	205 MPa (30 ksi)
Elongation (in 2" or 50mm), min	35%
Hardness (HBW), max	183

Application

Usage Mode	Application Focus	Key Advantage
As Pipe (A312)	Fluid transmission, chemical processing, sanitary lines	Corrosion resistance, ease of welding, ready-to-use
As Blank (Hollow Bar)	Flanges, valve bodies, large fittings, mechanical parts	Near-net shape, minimal machining, high material utilization
