| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | TP317, TP317L |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-Wooden Case /Iron Case/ Bundle with Plastic Cap |
| Delivery Time: | 5 - 90 Work Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | According to Clients' Requirement |
| Standard: | ASTM A312, ASME SA312 | Material Grade: | TP317, TP317L |
|---|---|---|---|
| Type: | Seamless | Shape: | Round |
| Outer Diameter: | 6mm-630mm Or Customized | Thickness: | 0.4-30mm |
| Length: | 6 Meters Or Customized | Applications: | Construction,Decoration,Industry,Boiler,Chemical |
| High Light: | ASTM A312 Stainless Steel Seamless Tubes,317L Stainless Steel Welded Tubes,Seamless Stainless Steel Heat Exchanger Tubes |
||
ASTM A312 TP317, TP317L Stainless Steel Welded Pipe For Oil And Gas Plants
ASTM A312 TP317L Stainless Steel is a low carbon austenitic grade. The Stainless Steel TP317L Pipe consists of iron, chromium, nickel, molybdenum, manganese, silicon, phosphorous, carbon, and sulfur. Stainless Steel TP317L Pipe works well in water conditions due to the content of molybdenum. The lower carbon content makes them to be resistant to sensitization and gives them higher creep-rupture properties.
Equivalent Grades:
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
Specifications:
| Specification | ASTM A312 / ASME SA312 |
| Size | 1 / 8" NB - 24" NB |
| Types | Seamless - Hot Rolled / Cold Drawn; Welded |
| Length | Single Random, Double Random & Required Length |
| Outer Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB |
| Thickness | 0.3mm – 50 mm |
| Schedule | SCH10 - SCHXXS |
| Form | Round, Square, Rectangular, Hot Finish, Cold Drawn |
| End | Plain End, Beveled End, Treaded |
Chemical Properties:
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | |
| SS317L | min. | - | - | - | - | - | 18 | 3 | 11 |
| max. | 0.03 | 2 | 0.75 | 0.04 | 0.03 | 20 | 4 | 15 | |
Mechanical Properties:
| Tensile strength | 595 MPa - 86300 Psi |
| Yield strength | 260 MPa - 37700 Psi |
| Elongation at break (in 50 mm) | 55% |
| Hardness, Rockwell B | 85 |
Applications:
Power Plant
Paper & Pulp Industry
Chemical Industry
Food Processing Industry
Fabrication Industry
Oil and Gas Plant
Water Supply Equipments
