Yuhong Holding Group Co.,LTD
Place of Origin: | CHINA |
Brand Name: | YUHONG |
Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
Model Number: | ASTM A554 TP304 |
Minimum Order Quantity: | 100 KGS |
---|---|
Price: | NEGOTIABLE |
Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
Delivery Time: | 5-80 days |
Payment Terms: | T/T, L/C, Western Union |
Supply Ability: | 1500 Tons Per Month |
Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series | Type: | Welded, Round Pipe |
---|---|---|---|
Standard: | ASTM, AISI, GB, DIN, JIS | Certification: | ISO, SGS, BV, ISO & SGS, ISO/CE/SGS |
Length: | 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m | Thickness: | 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm |
Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them | Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube |
Outer Diameter: | 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm | Surface: | Annealing, 8K, Polishing Or Unpolishing, Morror/Satin |
Finish: | Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright | ||
Highlight: | TP304 Stainless Steel Welded Pipe,ASTM A554 Stainless Steel Welded Pipe,ASTM A554 TP304 pipe |
ASTM A554 TP304 Weld Pipe
Overview
ASTM A554 is a specification published by ASTM International that covers stainless steel mechanical tubing. However, there seems to be some confusion in your query as "TP304" is not directly associated with ASTM A554. Instead, TP304 refers to a specific grade of stainless steel, which is typically covered under different ASTM standards.
Grade | Carbon | Nickel | Manganese | Sulfur | Chromium | Phosphorus | Silicon |
304 | 0.08 | 8.0-11.0 | 2 | 0.03 | 18.0-20.0 | 0.045 | 1 |
Material | Temperure | Heat | Yield Strength | Tensile Strength | Elongation |
Min.º F(º C) | Treatment | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
304 | 1900 (1040) | Solution | 30(205) | 75(515) | 35 |
Grade | Unified Numbering System | Euronorm | Old British | Swedish SS | Japanese Industrial Standards | ||
No | Name | British Standards | European Standards | ||||
ASTM A554 TP304 | S30400 | 1.4301 | X5CrNi18-10 | 304S31 | 58E | 2332 | SUS 304 |
Grade |
Mean Coefficient of Thermal Expansion (μm/m/°C) | Density (kg/m3) | Elastic Modulus (GPa) | Specific Heat 0-100°C (J/kg.K) | Thermal Conductivity (W/m.K) | Electrical Resistivity (nΩ.m) | |||
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
TP304 | 17.2 | 17.8 | 18.4 | 8000 | 193 | 500 | 16.2 | 21.5 | 720 |
Applications of ASTM A554 TP304 Welded Pipes:
1. Food Processing Industry
2. Pharmaceutical Industry
3. Chemical Processing Industry
4. Oil and Gas Industry
5. Architecture and Construction
6. Marine Applications
7. Heating, Ventilation, and Air Conditioning
8. Water Treatment Plants
9. Agricultural Equipment
